CMOS Switching Regulator (PWM controlled) MM3005~MM3010
CMOS Switching Regulator (PWM controlled)
Monolithic IC MM3005~MM3010
Outline
This IC is a PWM controlled switching regulator developed using the CMOS process. Low ripple and high
efficiency of 83% typ. (MM3005E) are achieved through PWM control. Further, output voltage is high
precision output ±2.4%.
Features
1. Ultra low consumption current 17.2µA typ. (during operation) (MM3005E)
2. High efficiency 83% typ. (MM3005E)
3. High precision output voltage ±2.4%
4. Wide operating temperature range -30°C~+85°C
5. Output voltage 2~5.5V (0.1V can be set in 0.1V steps)
Package
SOT-25A (Mini mold)
Applications
1. Mobile phones, PHS
2. Portable MD
3. Other battery-operated portable equipment
Block Diagram
MM3005
MITSUMI
CMOS Switching Regulator (PWM controlled) MM3005~MM3010
MM3006
MM3007
MM3008
MITSUMI
CMOS Switching Regulator (PWM controlled) MM3005~MM3010
MM3009
MM3010
Pin Assignment
MM3005
1
5
4
2
3
1
2
3
4
5
SOT-25A
(TOP VIEW)
ON/OFF
V
OUT
NC
V
SS
CONT
SOT-25A
(TOP VIEW)
1
2
3
5
4
MM3006
1
2
3
4
5
ON/OFF
V
OUT
NC
V
SS
EXT
MITSUMI
CMOS Switching Regulator (PWM controlled) MM3005~MM3010
MM3007
1
5
4
2
3
1
2
3
4
5
SOT-25A
(TOP VIEW)
NC
V
OUT
NC
V
SS
CONT
MM3008
1
5
4
2
3
1
2
3
4
5
SOT-25A
(TOP VIEW)
NC
V
OUT
NC
V
SS
EXT
MM3009
1
5
4
2
3
1
2
3
4
5
SOT-25A
(TOP VIEW)
V
OUT
V
DD
NC
V
SS
CONT
MM3010
1
5
4
2
3
1
2
3
4
5
SOT-25A
(TOP VIEW)
V
OUT
V
DD
NC
V
SS
EXT
Absolute Maximum Ratings
Item
Storage Temperature
Operating Temperature
Power Supply Voltage
Allowable loss
V
OUT
pin voltage
ON/OFF pin voltage
CONT pin voltage
CONT pin current
Symbol
T
STG
T
OPR
V
DD
max.
Pd
V
OUT
ON/OFF
V
CONT
I
CONT
Rating
-40~+125
-30~+85
-0.3~+11
150
-0.3~+11
-0.3~+11
-0.3~+11
300
Unit
°C
°C
V
mW
V
V
V
mA
Recommended Operating Conditions
Item
Operating Temperature
Input voltage
Symbol
T
OPR
V
IN
Rating
-30~+85
+0.9~+9
Unit
°C
V
Rank expand table
MM3005A
MM3005C
MM3005E
MM3005G
MM3005J
Ta=25°C
2.0V±2.4%
2.7V±2.4%
3.0V±2.4%
3.6V±2.4%
5.2V±2.4%
MM3005B
MM3005D
MM3005F
MM3005H
MM3005K
2.5V±2.4%
2.8V±2.4%
3.3V±2.4%
5.0V±2.4%
5.4V±2.4%
*
In addition to MM3005, MM3006 ~ MM3010 also have rank indications from A ~ K, as above.
MITSUMI
CMOS Switching Regulator (PWM controlled) MM3005~MM3010
Electrical Characteristics
(Except where noted otherwise, Ta=25°C)
MM3005, MM3007, MM3009 (It is L rank only MM3009.)
Item
Input voltage
Operating start voltage
Oscillation start voltage
Operation hold voltage
Symbol
V
IN
V
ST1
V
ST2
V
HLD
Measurement
circuit
1
1
2
1
Measuring Circuit
Rank Min. Typ. Max. Unit
9
0.9
0.8
0.7
A
B
C
D
E
F
G
H
J
K
L
A
B
C
D
E
F
G
H
J
K
L
A
B
C
D
E
F
G
H
J
K
L
11.6
14.3
15.5
16.1
17.2
19.1
22.4
38.5
43.9
45.0
13.2
3.1
3.2
3.2
3.2
3.2
3.3
3.3
3.5
3.5
3.5
3.1
71
98
98
98
125
125
125
182
182
182
71
30
30
±50
42.5
75
3
50
83
6
57.5
90
12
19.4
23.9
25.9
26.8
28.7
31.8
37.3
64.1
73.1
74.9
22.8
6.2
6.3
6.4
6.4
6.4
6.5
6.5
6.9
6.9
6.9
6.2
V
V
V
V
I
OUT
=1mA
I
OUT
=1mA
Consumption current 1
I
SS1
V
OUT
= Output voltage 0.95
µA
2
Consumption current 2
I
SS2
V
OUT
= Output voltage+0.5V
µA
Switching current
I
SW
V
CONT
=0.4V
45
61
61
61
78
78
78
114
114
114
45
mA
Switching transistor leak current
I
SWO
Input stability
V
OUT1
Load stability
V
OUT2
Output voltage
V
OUT
temperature coefficient
Ta
Oscillation frequency
fosc
Maximum duty ratio
MaxDuty
Soft start
Tss
1
1
1
2
2
V
OUT
=V
CONT
=9V
V
IN
= Output voltage 0.4 0.6
I
OUT
=10µA~I
OUT
(Following) 1.25
Ta= -30~85°C
V
OUT
= Output voltage 0.95
V
OUT
= Output voltage 0.96
I
OUT
=1mA
1
60
60
µA
mV
mV
ppm/°C
kHz
%
ms
