ESD5V0J4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> ESD5V0J4

ESD5V0J4: DescriptionTrans Voltage Suppressor Diode, 200W, 5V V(RWM), Unidirectional, 4 Element, Silicon, PLASTIC PACKAGE-5; CategoryDiscrete semiconductor diode; File Size116KB，4 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric View All

ESD5V0J4 Overview

Trans Voltage Suppressor Diode, 200W, 5V V(RWM), Unidirectional, 4 Element, Silicon, PLASTIC PACKAGE-5

ESD5V0J4 Parametric

Parameter Name	Attribute value
Maker	Micro Commercial Components (MCC)
package instruction	R-PDSO-G5
Contacts	5
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum breakdown voltage	7.2 V
Minimum breakdown voltage	6 V
Configuration	COMMON ANODE, 4 ELEMENTS
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	R-PDSO-G5
Maximum non-repetitive peak reverse power dissipation	200 W
Number of components	4
Number of terminals	5
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.15 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	5 V
surface mount	YES
technology	AVALANCHE
Terminal form	GULL WING
Terminal location	DUAL
Base Number Matches	1

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

20736 Marilla Street Chatsworth

CA91311

Phone: (818) 701-4933

Fax: (818) 701-4939

ESD5V0J4

Features

•

For sensitive ESD protection

Excellent clamping capability

Low leakage

ESD rating of class 3(>16KV)per Human Body Mode

For space saving application

Fast response ,response time less than 1ns.

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0

5 Volts

ESD Protector

SOT-353

Maximum Ratings

•

Operating Junction &StorageTemperature: -55°C to +150°C

Maximum Thermal Resistance; 833°C/W Junction To Ambient

Symbol

Air

Contact

Limits

f30

400

150

200

unit

Parameter

IEC61000-4-2(ESD)

ESD Voltage per human body mode

per machine mode

Power Dissipation(Note 1)

Peak Power Dissipation@8/20us

Ppk

1.Only 1 diode under power. For all 4 diodes under power,

PD will be 25%. Mounted on FR--4 board with min pad.

Pin Configuration

DIM

INCHES

MIN

MAX

MIN

0.90

.00

.900

.150

.080

2.0

1.15

2.15

.035

.043

.00

.004

.035

.039

.006

.014

.003

.006

.079

.087

.045

.053

.085

.096

.026 TYP

.047

.055

.021 REF

.010

.018

MAX

1.10

.100

1.00

.350

.150

2.2

1.35

2.45

.650 TYP

1.2

1.4

.525 REF

.260

.460

www.mccsemi.com

Revision:

2007/12/18
