MAD26027: Description10 WATTS SINGLE & DUAL OUTPUT DC/DC INDUSTRIAL; File Size516KB，2 Pages; ManufacturerPowerbox; Websitehttps://www.powerbox.com

Download Datasheet View All

MAD26027 Overview

10 WATTS SINGLE & DUAL OUTPUT DC/DC INDUSTRIAL

Preview

Download Datasheet

View All

MODULES

MAD 26 Series

1 0

W AT T S

S I N G L E

D U A L

O U T P U T

D C / D C

I N D U S T R I A L

Features

•

4:1 Input range

Meet EN55022 class A

500 VDC isolation

24-pin DIP Package

Efficiency to 80 %

Six-sided shield

Specifications

INPUT

Nominal voltage

Voltage range

Isolation

Filter

OUTPUT

Power

Regulation

Load transient response

Setting accuracy

Ripple and noise

Short circuit protection

Temp coefficient

Efficiency

ENVIRONMENTAL

Operating temperature

Storage temperature

Cooling

GENERAL

MTTF

Switching frequency

Equivalent capacitance

Case

Dimensions (H x W x L)

Weight

STANDARDS

EMI standards

C-Tick

EN55022 class A.

AS/NZS CISPR11 Group 1 Class A

200 000 hours at 25°C ambient.

Min. 200 kHz.

3000 pF.

Black coated copper with non-conductive

black base.

10.2 x 25.4 x 50.8 mm.

35g.

–25°C to +71°C.

–40°C to +100°C.

Convection.

10W.

Line: ±0.2% max

Load: ± 1.0 max

<480µs.

± 1%.

Max. 75 mVp-p.

Fold-back. Approx 80% of output current at

short circuit.

±0.02 %/°C.

77% to 82%.

24V, 48V.

9-36V, 18-72V.

500VDC.

PI-type

Technical Illustration

178
