RF-18
TNC–J–C–GN–ST–BH1
TNC–J–P–H–RA–TH1
TNC SERIES
50
W
TNC JACKS & PLUGS
Mates with:
RF058, RF178, RF316,
RF174, GRF1H-C
TNC
GENDER
TYPE
PLATING
ORIENTATION
TERMINATION
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?TNC-TH
Outer Contact Material:
Ni plated Brass
Center Contact Material:
Au plated Phosphor
Bronze
Insulator Material:
PTFE
Operating Temperature:
-65 °C to +125 °C
Impedance:
50
W
Frequency Range:
0~6 GHz
Working Voltage:
500 Vrms max
Dielectric Withstanding:
1500 Vrms min
RoHS Compliant:
Yes
= Jack
–J
= PCB
Mount
–P
= 30 µ"
(0.76 µm)
Gold on
center
contact,
Nickel on
Shell
–H
= Right-angle
–RA
= Through-hole
–TH1
(31.10) 1.224
(18.00)
.709
PROCESSING
Lead–Free Solderable:
Yes
Note:
While optimized for 50
W
applications, this connector
can also perform well in certain 75
W
applications.
Contact RFGroup@samtec.com for further information.
(3.00)
.118
(1.00) .039 DIA
SPECIFICATIONS
For complete specifications
and assembly instructions see
www.samtec.com?TNC-CA
TNC
GENDER
TYPE
PLATING
ORIENTATION
TERMINATION
Shell Material:
Brass
ALSO
Contact Material:
Brass (–P–ST),
AVAILABLE
Phosphor Bronze (–J)
(MOQ Required)
Center Contact:
Soldered
• IP67 sealed option
Outer Ferrule:
Contact Samtec.
Crimped
Impedance:
50
W
Frequency Range:
0~3 GHz (Cable dependent)
Working Voltage:
500 Vrms max
Dielectric Withstanding:
1500 Vrms min
Operating Temp Range:
-65 °C to +125 °C
= Plug
–P
–J
= Cable
–C
= Jack
= 10 µ"
(0.25 µm)
Gold on
contact,
Nickel on
body
–GN
= Straight
–ST
= Straight
Reverse Polarity
(–P only)
–SR
= RG 174 / 316 Cable
(–P & –ST only)
= RG 178 Cable
(–P & –ST only)
= RG 58 Cable
(–P & –SR only)
= Bulkhead,
RG 174 / 316 Cable
(–J & –ST only)
= Bulkhead,
RG 178 Cable
(–J & –ST only)
–CA1
–CA2
–C10
(29.80) 1.173
(18.70) .736
(2.70)
.106
(25.00) .984
(17.00) .669
(15.00) .590
–BH1
–BH2
(17.50)
.689
Hex.
(14.50)
.571
–J
–P
Supplied with pins, washers, nuts and ferrules. See website for dimensions.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
