HD74HC442T datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > logic> logic> HD74HC442T

Preview

HD74HC442T: DescriptionHC/UH SERIES, 4-BIT EXCHANGER, TRUE OUTPUT, PDSO20, TSOP-20; Categorylogic logic; File Size103KB，3 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

HD74HC442T Overview

HC/UH SERIES, 4-BIT EXCHANGER, TRUE OUTPUT, PDSO20, TSOP-20

HD74HC442T Parametric

Parameter Name	Attribute value
Maker	Renesas Electronics Corporation
Parts packaging code	TSOP
package instruction	TSSOP,
Contacts	20
Reach Compliance Code	unknown
Other features	UNIVERSAL EXCHANGER
series	HC/UH
JESD-30 code	R-PDSO-G20
length	6.5 mm
Logic integrated circuit type	BUS EXCHANGER
Number of digits	4
Number of functions	1
Number of ports	3
Number of terminals	20
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output characteristics	3-STATE
Output polarity	TRUE
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
propagation delay (tpd)	50 ns
Certification status	Not Qualified
Maximum seat height	1.1 mm
Maximum supply voltage (Vsup)	6 V
Minimum supply voltage (Vsup)	2 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
width	4.4 mm
Base Number Matches	1

Preview

Download Datasheet

View All

HD74HC442T Related Products

	HD74HC442T	HD74HC443T	HD74HC444T
Description	HC/UH SERIES, 4-BIT EXCHANGER, TRUE OUTPUT, PDSO20, TSOP-20	HC/UH SERIES, 4-BIT EXCHANGER, INVERTED OUTPUT, PDSO20, TSOP-20	HC/UH SERIES, 4-BIT EXCHANGER, TRUE OUTPUT, PDSO20, TSOP-20
Maker	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation
Parts packaging code	TSOP	TSOP	TSOP
package instruction	TSSOP,	TSSOP,	TSSOP,
Contacts	20	20	20
Reach Compliance Code	unknown	compliant	compliant
Other features	UNIVERSAL EXCHANGER	UNIVERSAL EXCHANGER	UNIVERSAL EXCHANGER
series	HC/UH	HC/UH	HC/UH
JESD-30 code	R-PDSO-G20	R-PDSO-G20	R-PDSO-G20
length	6.5 mm	6.5 mm	6.5 mm
Logic integrated circuit type	BUS EXCHANGER	BUS EXCHANGER	BUS EXCHANGER
Number of digits	4	4	4
Number of functions	1	1	1
Number of ports	3	3	3
Number of terminals	20	20	20
Maximum operating temperature	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C
Output characteristics	3-STATE	3-STATE	3-STATE
Output polarity	TRUE	INVERTED	TRUE
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TSSOP	TSSOP	TSSOP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
propagation delay (tpd)	50 ns	50 ns	50 ns
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.1 mm	1.1 mm	1.1 mm
Maximum supply voltage (Vsup)	6 V	6 V	6 V
Minimum supply voltage (Vsup)	2 V	2 V	2 V
Nominal supply voltage (Vsup)	5 V	5 V	5 V
surface mount	YES	YES	YES
technology	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	GULL WING	GULL WING	GULL WING
Terminal pitch	0.65 mm	0.65 mm	0.65 mm
Terminal location	DUAL	DUAL	DUAL
width	4.4 mm	4.4 mm	4.4 mm
Base Number Matches	1	1	1
