C-13/15-F02M-P-SSTM-GR

Description
Fiber Optic Device, 1290nm Min, 1330nm Max, ST Connector, Through Hole Mount, ROHS COMPLIANT PACKAGE
CategoryWireless rf/communication    Optical fiber
File Size181KB,6 Pages
ManufacturerSource Photonics
Environmental Compliance
Download Datasheet Parametric View All

C-13/15-F02M-P-SSTM-GR Overview

Fiber Optic Device, 1290nm Min, 1330nm Max, ST Connector, Through Hole Mount, ROHS COMPLIANT PACKAGE

C-13/15-F02M-P-SSTM-GR Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerSource Photonics
Reach Compliance Codeunknown
Other featuresIT ALSO OPERATES FROM 1480 TO 1600 NM WAVELENGTH
body height8.2 mm
Body length or diameter6.35 mm
Connection TypeST CONNECTOR
Fiber type9/125, SMF
Installation featuresTHROUGH HOLE MOUNT
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Maximum operating wavelength1330 nm
Minimum operating wavelength1290 nm
Nominal operating wavelength1310 nm
Nominal optical power output0.75 mW
surface mountNO
Base Number Matches1
P/N: C-13/15-FXXM-PX-XXXX/XXX-XX
1310nm Emitting, 1550nm Receiving (PIN-TIA,5 pin-out, 3.3V)
Bi-directional Diplexer Optical Module
Features
Single fiber bi-directional operation
Laser diode with multi-quantum- well structure
Low threshold current
InGaAs/InP PIN Photodiode with trans-impedance amplifier
High sensitivity with AGC*
Differential ended output
Single +3.3V Power Supply
Integrated WDM coupler
Un-cooled operation from –40°C to +85°C
Hermetically sealed active component
SM/MM fiber pigtailed packaging with optional FC/ST/SC/MU/LC
connector
Design for fiber optic networks application
RoHS Compliant available
Absolute Maximum Ratings (Tc=25°C)
Parameter
Fiber Output Power
LD Reverse Voltage
PIN-TIA Voltage
Operating Temperature
Storage Temperature
L/M/H
Symbol
P
f
V
RLD
V
CC
T
opr
T
stg
Rating
1(L)/1.5(M)/2.5(H)
2
4.5
-40 ~ 85
-40 ~ 85
Unit
mW
V
V
°C
°C
(All optical data refer to a coupled 9/125
μ
m SM & 50/125
μ
m MM fiber)
Optical and Electrical Characteristics
Parameter
Laser Diode
L
Optical Output Power
Peak Wavelength
Spectrum Width (RMS)
Threshold Current
Forward Voltage
Rise Time / Fall Time
Monitor Diode
Monitor Current
Dark Current
Capacitance
I
m
I
dark
C
t
100
-
-
-
-
6
1
DS-6001 Rev 0.0 2010-02-22
(Tc=25°C)
Min.
Typ.
Max.
Unit
Notes
Symbol
0.2
P
f
λ
Δλ
Ith
V
F
T
r
/ T
f
0.5
1
1290
-
-
-
-
0.35
0.75
1.6
1310
-
10
1.2
-
0.5
1
-
1330
5
15
1.5
0.5
nm
nm
mA
V
ns
μA
μA
pF
CW, P
f
= P
f
(Min)
CW, P
f
= P
f
(Min)
CW
CW, P
f
= P
f
(Min)
Ibias=Ith, 10% to 90%
CW, P
f
= P
f
(Min), V
RPD
= 2V
V
RPD
= 5V
V
RPD
= 5V, f = 1MHz
mW
CW, Ith+20mA, kink free
M
H
-
0.1
15
