Proximity Sensors
Extended Range Metal Cylindrical Sensors
3-Wire DC Type
922 Series
Dimensions
Type of Package
Sensing Distance,
mm (in.)
Repeatability
Hysteresis
Switching
Frequency
Circuit Protection
Protection Class
Operating
Temperature
Shock/Vibration
Termination
Housing Material
Output Indicator
3-Wire DC
Supply
Voltage
Shielded
2,2 (.09)
<±2%
4 - 20%
0.5 kHz
M8
Shielded
2,2 (.09)
<±2%
4 - 20%
0.5 kHz
Shielded
4,0 (.16)
<±2%
4 - 20%
0.5 kHz
M12
Shielded
4,0 (.16)
<±2%
4 - 20%
0.5 kHz
Shielded
8,0 (.31)
<±2%
4 - 20%
0.5 kHz
M18
Shielded
8,0 (.31)
<±2%
4 - 20%
0.5 kHz
Short circuit, Reverse polarity
UL, CSA, CE/IP 67
–25 to
+80°C
(– 13 to
+176°F)
30 g, 11 ms/10–50 Hz, 3 axes
PVC wires
Connector
Stainless Steel
Amber/Orange LED
10 to 30 VDC
160 mA, max.
10 A, max.
≤
1 VDC
922AC08YI-A3N
922AC08YI-B3N
922AC08YI-A3P
922AC08YI-B3P
922AC08RI-A3N
922AC08RI-B3N
922AC08RI-A3P
922AC08RI-B3P
Short circuit, Reverse polarity
UL, CSA, CE/IP 67
– 25 to
+80°C
(– 13 to
+176°F)
30 g, 11 ms/10–50 Hz, 3 axes
PVC wires
Brass
Amber/Orange LED
10 to 30 VDC
200 mA, max.
50 A, max.
≤
1 VDC
922AC12XM-A3N
922AC12XM-B3N
922AC12XM-A3P
922AC12XM-B3P
922AC12BM-A3N
922AC12BM-B3N
922AC12BM-A3P
922AC12BM-B3P
Connector
Short circuit, Reverse polarity
UL, CSA, CE/IP 67
– 25 to
+80°C
(– 13 to
+176°F)
30 g, 11 ms/10–50 Hz, 3 axes
PVC wires
Brass
Amber/Orange LED
10 to 30 VDC
200 mA, max.
50 A, max.
≤
1 VDC
922AC18XM-A3N
922AC18XM-B3N
922AC18XM-A3P
922AC18XM-B3P
922AC18BM-A3N
922AC18BM-B3N
922AC18BM-A3P
922AC18BM-B3P
Connector
Load Current
Leakage Current
Voltage Drop
NPN, N.O.
NPN, N.C.
PNP, N.O.
PNP, N.C.
WIRING DIAGRAMS
MATING CONNECTOR CABLES
Style
Straight
Straight
Straight
Right Angle
Right Angle
Right Angle
Length
2 meter
5 meter
2 meter
2 meter
5 meter
2 meter
Output
Type
N.O.
N.O.
N.C.
N.O.
N.O.
N.C.
Catalog
Listing
803000A09M020
803000A09M050
804000A09M020
803001A09M020
803001A09M050
804001A09M020
B22
