Document 584-1
SMT Power Inductors – EPL2010 Series
• Smallest shielded power inductors; 2.0 × 2.0 × 1 mm high
• Extremely low DCR and very high SRF ratings
•
Isat
ratings as high as 2.6 A
Designer’s Kit C412
contains 5 each of all values
Core material
Ferrite
Terminations
RoHS compliant tin-silver over gold over nickel over
silver. Other terminations available at additional cost.
Weight
13 – 18 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Mean Time Between Failures (MTBF)
26,315,789 hours
Packaging
2000/7″reel; 7500/13″ reel Plastic tape: 8 mm wide,
0.28 mm thick, 4 mm pocket spacing, 1.3 mm pocket depth
PCB washing
Only pure water or alcohol recommended
Inductance
2
±20% (µH)
0.30
0.47
0.68
0.82
1.0
1.5
2.2
3.3
4.7
6.8
8.2
10
DCR nom
3
(Ohms)
0.032
0.040
0.058
0.068
0.086
0.141
0.202
0.272
0.429
0.512
0.827
0.914
DCR max
3
(Ohms)
0.038
0.048
0.070
0.082
0.103
0.155
0.222
0.299
0.472
0.563
0.910
1.00
SRF typ
4
(MHz)
412
283
214
173
145
102
80
63
50
46
42
33
2.
3.
4.
5.
Part number
1
EPL2010-301ML_
EPL2010-471ML_
EPL2010-681ML_
EPL2010-821ML_
EPL2010-102ML_
EPL2010-152ML_
EPL2010-222ML_
EPL2010-332ML_
EPL2010-472ML_
EPL2010-682ML_
EPL2010-822ML_
EPL2010-103ML_
Isat
(A)
5
10% drop 20% drop 30% drop
1.2
1.0
0.80
0.70
0.65
0.60
0.43
0.35
0.30
0.24
0.22
0.20
2.1
1.6
1.3
1.2
1.0
0.95
0.78
0.63
0.47
0.43
0.40
0.35
2.6
2.2
2.0
1.6
1.35
1.30
1.05
0.85
0.65
0.57
0.53
0.47
Irms
(A)
6
20°C rise 40°C rise
1.76
1.66
1.48
1.28
1.04
0.799
0.751
0.671
0.527
0.440
0.415
0.392
2.31
2.16
1.94
1.68
1.36
1.04
0.978
0.879
0.680
0.575
0.520
0.495
1. When ordering, please specify
termination
and
packaging
codes:
EPL2010-103MLC
Termination: L
= RoHS compliant tin-silver over gold over nickel over
silver.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked (7500 parts per
full reel).
Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc.
DCR measured on a micro-ohmmeter.
SRF measured using Agilent/HP 4395A network analyzer or equivalent.
DC current at which the inductance drops the specified amount from its
value without current.
6. Current that causes the specified temperature rise from 25°C ambient.
7. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 584-1
Revised 04/21/08
© Coilcraft, Inc. 2008
