RL-7700-1C, RL-7700-2C
RL-7700-3C, RL-7700-4C
STANDARD CERAMIC WIREWOUND CHIP INDUCTORS
FEATURES
• Ceramic core wire wound construction.
• No batch to batch variations in inductance.
• High reliability due to ceramic wirewound construc-
tion.
APPLICATIONS
Widely used in the communication applications such as
cellular phones, pagers and other high frequency elec-
tronics devices.
SPECIFICATIONS
Operating Temperature range: -40°C to +125°C
Storage Temperature: -40°C to +125°C
B
F
C
I
J
I
A
G
F
H
E
D
P C B PAT T E R N
PART NUMBER IDENTIFICATION
RL-7700 -2
C
4N7 K
(1)
(2)
(3)
(4) (5)
(1) SERIES NAME
(2) DIMENSIONS
(3) TYPE CODE C - Ceramic
(4) INDUCTANCE CODE
(5) TOLERANCE CODE
G - ±2%
J - ±5%
K - ±10%
MECHANICAL DIMENSIONS (mm)
Part Number
RL-7700-1C
RL-7700-2C
RL-7700-3C
RL-7700-4C
A Max.
1.27
1.80
2.29
2.92
PRECAUTIONS
• After mounting components onto printed circuit
board, be careful not to bend or mishandle the
board.
• When hand soldering, apply solder iron to the printed
circuit board only. Temperature of the iron tip should
not exceed 260°C with soldering time < 3 seconds.
• Reflow soldering condition:
230°C for 10s max.
PACKAGING
Part Number
RL-7700-1
RL-7700-2
RL-7700-3
RL-7700-4
Pieces per reel
4,000
4,000
2,000
2,000
Plastic reel size
7”
7”
7”
7”
B Max. C Max. D Ref.
0.76
1.12
1.73
2.79
0.61
1.02
1.52
2.03
0.15
0.38
0.51
0.65
E Max. F Max. G Max. H Max. I Max. J Max.
0.51
0.76
1.27
2.03
0.23
0.33
0.44
0.51
0.56
0.86
1.02
1.52
0.66
1.02
1.78
2.54
0.50
0.64
1.02
1.02
0.46
0.64
0.76
1.27
RENCO ELECTRONICS, INC.
595 International Place, Rockledge, FL 32955-4200 USA
(321) 637-1000 • Toll Free Engineering Hot line 800-645-5828
154
SINCE 1955
Fax: (321) 637-1600
Web Site:www.rencousa.com
E-mail:sales@rencousa.com
Part
Number
Tolerance
Available
L
(nH)
Test
Freq.
(MHz)
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
Q
Min.
SRF
Min.
(MHz)
6000
6000
6000
6000
6000
5800
5800
5800
5800
5800
4400
4160
3900
3680
3600
3280
3040
2720
2480
2320
2240
2100
2000
DCR
Max.
(Ω)
0.045
0.070
0.070
0.066
0.066
0.066
0.083
0.083
0.083
0.104
0.104
0.104
0.195
0.120
0.120
0.172
0.202
0.214
0.298
0.403
0.500
0.830
1.117
IDC 900 MHz 900 MHZ
Max.
L
Q
(mA)
Typ.
Typ.
1360
1040
960
840
840
840
800
760
760
680
680
680
480
640
640
560
480
400
400
320
320
250
200
1.02
1.93
2.19
3.10
3.56
3.89
5.15
5.16
6.16
7.91
8.50
9.07
9.80
10.70
11.90
14.60
19.10
23.80
28.70
39.50
39.00
50.00
-
77
54
59
65
45
50
56
54
52
60
57
62
50
52
53
55
50
49
49
44
44
38
-
1.7GHz
L
Typ.
1.02
1.93
2.23
3.12
3.62
4.00
5.25
5.28
6.37
8.22
8.85
9.53
10.10
11.20
12.70
15.50
21.10
26.90
33.50
48.40
47.40
-
-
1.7 GHz
Q
Typ.
69
75
100
87
71
75
82
81
76
88
84
78
67
78
71
77
67
64
63
53
33
-
-
RL-7700-1C-1N0
RL-7700-1C-2N0
RL-7700-1C-2N2
RL-7700-1C-3N3
RL-7700-1C-3N6
RL-7700-1C-3N9
RL-7700-1C-5N1
RL-7700-1C-5N6
RL-7700-1C-6N2
RL-7700-1C-7N5
RL-7700-1C-8N2
RL-7700-1C-9N0
RL-7700-1C-10N
RL-7700-1C-11N
RL-7700-1C-12N
RL-7700-1C-15N
RL-7700-1C-19N
RL-7700-1C-23N
RL-7700-1C-27N
RL-7700-1C-36N
RL-7700-1C-40N
RL-7700-1C-47N
RL-7700-1C-56N
K
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
K,J
1.0
2.0
2.2
3.3
3.6
3.9
5.1
5.6
6.2
7.5
8.2
9.0
10.0
11.0
12.0
15.0
19.0
23.0
27.0
36.0
40.0
47.0
56.0
16
16
19
19
19
19
20
20
20
22
22
22
21
24
24
24
24
24
24
24
24
20
25
Test Equipment: Agilent / HP 4287 + Agilent / HP 8753D or HP 4291A
