INDUCTORS
ØW
ØW
1
1
2
2
H
H
FERRITE CORE
POWER INDUCTOR
LPC 9040N
LPC 9040E
A
A
STRUCTURE
3
3
1
2
3
4
5
Ferrite core
Winding wire
Electrode
Terminal 1
Terminal 2
IDENTIFICaTION
PRODUCT CODE
LPC 9040N
LPC 9040E
COaTINg COLOR
Clear
MaRKINg
None
Products with Pb-free terminations
meet EU-RoHS requirements
TYPE DESIgNaTION (HOW TO ORDER)
Contact our sales representatives before you use our products for applications including
automotives, medical equipment and aerospace equipment. Malfunction or failure of the
products in such applications may cause loss of human life or serious damage.
LPC 9040E
PRODUCT CODE
LPC 9040N
LPC 9040E
a
TERMINATION
SURFACE MATERIAL
A: SnAg
TE
TAPING*
TE: 1.500 pcs/reel
BK: Bulk = 100 pcs
*Please see “PACKAGING”
470
NOMINAL
INDUCTANCE
3 digits
K
INDUCTANCE
TOLERANCE
K: (±10%)
M: (±20%)
Contact us when you have control request for environmental hazardous
material other than the substance specified by EU-RoHS
FEaTURES
■
■
■
■
■
■
■
■
Large permissible DC current and small DC resistance are realized
by the original construction and wiring technology
Automatic surface mounting is applicable
Excellent solderability and endurance environment
LPC 9040N = Operating temperature range: -40° C ... +85° C
LPC 9040E = Operating temperature range: -40° C ... +125° C*
LPC 9040E parts are tested according to AEC-Q200 requirements
Suitable for reflow soldering
Embossed carrier tape packaging available
DIMENSIONS (mm)
TYPE
LPC 9040
∅
W
9.0 ± 0.1
H
(max.)
4.9
a
(max.)
10.2
x
2.0 ± 0.2
y
2.0 ± 0.2
g
45° ± 6°
* Including self-temperature rise
RaTINg
TYPE
LPC 9040N a TE 100 M
LPC 9040N a TE 150 K
LPC 9040N a TE 220 K
LPC 9040N a TE 330 K
LPC 9040N a TE 470 K
LPC 9040N a TE 680 K
LPC 9040N a TE 101 K
LPC 9040N a TE 151 K
LPC 9040N a TE 221 K
LPC 9040N a TE 331 K
LPC 9040N a TE 471 K
LPC 9040N a TE 681 K
LPC 9040E a TE 100 M
LPC 9040E a TE 150 K
LPC 9040E a TE 220 K
LPC 9040E a TE 330 K
LPC 9040E a TE 470 K
LPC 9040E a TE 680 K
LPC 9040E a TE 101 K
LPC 9040E a TE 151 K
LPC 9040E a TE 221 K
LPC 9040E a TE 331 K
LPC 9040E a TE 471 K
LPC 9040E a TE 681 K
INDUCTaNCE
NOM. VaLUE*
10 µH
15 µH
22 µH
33 µH
47 µH
68 µH
100 µH
150 µH
220 µH
330 µH
470 µH
680 µH
10 µH
15 µH
22 µH
33 µH
47 µH
68 µH
100 µH
150 µH
220 µH
330 µH
470 µH
680 µH
TOLERaNCE
M (± 20%)
INDUCTaNCE
MEaSURINg
FREQUENCY
SELF-RESONaNT
FREQUENCY
(MIN.)
25.0 MHz
21.0 MHz
15.0 MHz
13.5 MHz
11.5 MHz
10.0 MHz
8.0 MHz
7.0 MHz
5.0 MHz
3.3 MHz
2.8 MHz
1.2 MHz
25.0 MHz
21.0 MHz
15.0 MHz
13.5 MHz
11.5 MHz
10.0 MHz
8.0 MHz
7.0 MHz
5.0 MHz
3.3 MHz
2.8 MHz
1.2 MHz
DC
RESISTaNCE
(MaX.)
0.07 Ω
0.09 Ω
0.11 Ω
0.14 Ω
0.20 Ω
0.27 Ω
0.41 Ω
0.55 Ω
0.81 Ω
1.86 Ω
2.07 Ω
2.65 Ω
0.07 Ω
0.09 Ω
0.11 Ω
0.14 Ω
0.20 Ω
0.27 Ω
0.41 Ω
0.55 Ω
0.81 Ω
1.86 Ω
2.07 Ω
2.65 Ω
aLLOWaBLE
DC CURRENT
(MaX.)
1.55 A
1.40 A
1.25 A
1.10 A
0.99 A
0.91 A
0.70 A
0.60 A
0.50 A
0.29 A
0.22 A
0.14 A
2.40 A
2.20 A
2.00 A
1.80 A
1.40 A
1.20 A
1.00 A
0.80 A
0.60 A
0.45 A
0.40 A
0.35 A
Specifications given herein may be changed at any time without prior notice.
Please confirm technical specifications before you order/or use.
K (± 10%)
1 kHz
M (± 20%)
K (± 10%)
1 kHz
* Other inductance values on request
Avoid strong pressure or excessive shock at mounting or after mounting because electric/magnetic characteristics may change if it is applied to the inductors.
Due to the products using ferrite for coil bobbins, use them within each operating temperature range because the volume of generating heat varies depending on switching frequency.
EUROPE GmbH • Kaddenbusch 6 • D-25578 Dägeling / ITZEHOE • PHONE: +49 (0) 48 21 / 89 89-0 • FAX: +49 (0) 48 21/ 89 89 89 • Internet: www.koaeurope.de
73
Revision: 07. Mar. 2011
