OP06G: DescriptionBasic information of OP06G amplifier: OP06G is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are 2.41 X 1.30 MM, DIE-8 OP06G amplifier core information: The minimum operating temperature of OP06G is and the maximum operating temperature is 70 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 0.08 µA Its minimum voltage gain is 1000000. The nominal supply voltage of OP06G is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of OP06G is 500000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions of OP06G: OP06G has 8 terminals. Its terminal position type is: UPPER. Total pins: 6 OP06G amplifier additional information: Its temperature grade is: COMMERCIAL. OP06G is not Rohs certified. The corresponding JESD-30 code is: R-XUUC-N8. The corresponding JESD-609 code is: e0. The packaging code of OP06G is: DIE. The OP06G package materials are mostly UNSPECIFIED. The package shape is RECTANGULAR. OP06G package pin formats are: UNCASED CHIP. Its terminal forms are: NO LEAD.; CategoryAnalog mixed-signal IC Amplifier circuit; File Size229KB，5 Pages; ManufacturerADI; Websitehttps://www.analog.com; Alternative parts：OP06G

Download Datasheet Parametric Compare View All

OP06G Overview

Basic information of OP06G amplifier:

OP06G is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are 2.41 X 1.30 MM, DIE-8

OP06G amplifier core information:

The minimum operating temperature of OP06G is and the maximum operating temperature is 70 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 0.08 µA

Its minimum voltage gain is 1000000.

The nominal supply voltage of OP06G is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of OP06G is 500000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of OP06G:

OP06G has 8 terminals. Its terminal position type is: UPPER. Total pins: 6

OP06G amplifier additional information:

Its temperature grade is: COMMERCIAL. OP06G is not Rohs certified. The corresponding JESD-30 code is: R-XUUC-N8. The corresponding JESD-609 code is: e0. The packaging code of OP06G is: DIE.

The OP06G package materials are mostly UNSPECIFIED. The package shape is RECTANGULAR. OP06G package pin formats are: UNCASED CHIP. Its terminal forms are: NO LEAD.

OP06G Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	ADI
Parts packaging code	DIE
package instruction	2.41 X 1.30 MM, DIE-8
Contacts	6
Reach Compliance Code	compliant
ECCN code	EAR99
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.08 µA
Minimum Common Mode Rejection Ratio	114 dB
Nominal Common Mode Rejection Ratio	114 dB
Maximum input offset voltage	500000 µV
JESD-30 code	R-XUUC-N8
JESD-609 code	e0
Negative supply voltage upper limit	-22 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	1
Number of terminals	8
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	UNSPECIFIED
encapsulated code	DIE
Package shape	RECTANGULAR
Package form	UNCASED CHIP
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Supply voltage upper limit	22 V
Nominal supply voltage (Vsup)	15 V
surface mount	YES
technology	BIPOLAR
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	NO LEAD
Terminal location	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED
Minimum voltage gain	1000000
Base Number Matches	1

Preview

Download Datasheet

View All

OP06G Related Products

	OP06G	OP06GT	OP06NT	OP06BIGZ	OP06AJ883C	OP06AJ/883C	OP06GR	OP06N
Description	IC OP-AMP, 500 uV OFFSET-MAX, UUC6, 2.41 X 1.30 MM, DIE-6, Operational Amplifier	IC OP-AMP, 700 uV OFFSET-MAX, UUC6, 2.41 X 1.30 MM, DIE-6, Operational Amplifier	IC OP-AMP, 300 uV OFFSET-MAX, UUC6, 2.41 X 1.30 MM, DIE-6, Operational Amplifier	IC OP-AMP, 1600 uV OFFSET-MAX, CDIP8, HERMETIC SEALED, CERDIP-8, Operational Amplifier	IC OP-AMP, MBCY8, TO-99, 8 PIN, Operational Amplifier	IC OP-AMP, 200 uV OFFSET-MAX, MBCY8, TO-99, 8 PIN, Operational Amplifier	IC OP-AMP, 1300 uV OFFSET-MAX, UUC6, 2.41 X 1.30 MM, DIE-6, Operational Amplifier	IC OP-AMP, 200 uV OFFSET-MAX, UUC6, 2.41 X 1.30 MM, DIE-6, Operational Amplifier
Maker	ADI	ADI	ADI	ADI	ADI	ADI	ADI	ADI
Parts packaging code	DIE	DIE	DIE	DIP	TO-99	TO-99	DIE	DIE
package instruction	2.41 X 1.30 MM, DIE-8	2.41 X 1.30 MM, DIE-6	2.41 X 1.30 MM, DIE-8	DIP,	TO-99, 8 PIN	TO-99, 8 PIN	2.41 X 1.30 MM, DIE-6	2.41 X 1.30 MM, DIE-6
Contacts	6	6	6	8	8	8	6	6
Reach Compliance Code	compliant	compliant	compliant	compliant	unknown	compliant	compliant	compliant
Is it Rohs certified?	incompatible	incompatible	incompatible	conform to	-	incompatible	incompatible	incompatible
ECCN code	EAR99	EAR99	EAR99	EAR99	-	EAR99	EAR99	EAR99
Amplifier type	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	-	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.08 µA	0.07 µA	0.06 µA	0.11 µA	-	0.07 µA	0.11 µA	0.07 µA
Minimum Common Mode Rejection Ratio	114 dB	108 dB	108 dB	-	-	-	110 dB	114 dB
Nominal Common Mode Rejection Ratio	114 dB	108 dB	108 dB	110 dB	-	112 dB	110 dB	114 dB
Maximum input offset voltage	500000 µV	700 µV	300000 µV	1600 µV	-	200 µV	1300 µV	200 µV
JESD-30 code	R-XUUC-N8	R-XUUC-N6	R-XUUC-N8	R-GDIP-T8	-	O-MBCY-W8	R-XUUC-N6	R-XUUC-N6
JESD-609 code	e0	e0	e0	-	-	-	e0	e0
Negative supply voltage upper limit	-22 V	-22 V	-22 V	-	-	-22 V	-22 V	-22 V
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V	-15 V	-15 V	-	-15 V	-15 V	-15 V
Number of functions	1	1	1	1	-	1	1	1
Number of terminals	8	6	8	8	-	8	6	6
Maximum operating temperature	70 °C	70 °C	-	70 °C	-	125 °C	70 °C	-
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	CERAMIC, GLASS-SEALED	-	METAL	UNSPECIFIED	UNSPECIFIED
encapsulated code	DIE	DIE	DIE	DIP	-	-	DIE	DIE
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	-	ROUND	RECTANGULAR	RECTANGULAR
Package form	UNCASED CHIP	UNCASED CHIP	UNCASED CHIP	IN-LINE	-	CYLINDRICAL	UNCASED CHIP	UNCASED CHIP
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	-	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified
Supply voltage upper limit	22 V	22 V	22 V	-	-	22 V	22 V	22 V
Nominal supply voltage (Vsup)	15 V	15 V	15 V	15 V	-	15 V	15 V	15 V
surface mount	YES	YES	YES	NO	-	NO	YES	YES
technology	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	-	-	BIPOLAR	BIPOLAR
Temperature level	COMMERCIAL	COMMERCIAL	-	COMMERCIAL	-	MILITARY	COMMERCIAL	-
Terminal surface	TIN LEAD	TIN LEAD	TIN LEAD	-	-	-	TIN LEAD	TIN LEAD
Terminal form	NO LEAD	NO LEAD	NO LEAD	THROUGH-HOLE	-	WIRE	NO LEAD	NO LEAD
Terminal location	UPPER	UPPER	UPPER	DUAL	-	BOTTOM	UPPER	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	-	NOT SPECIFIED	NOT SPECIFIED
Minimum voltage gain	1000000	800000	1000000	-	-	-	500000	1000000
