ECWF6273JLB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> ECWF6273JLB

ECWF6273JLB: DescriptionFilm Capacitor, Polypropylene, 630V, 5% +Tol, 5% -Tol, 0.027uF, Through Hole Mount, 5126, RADIAL LEADED; CategoryPassive components capacitor; File Size64KB，1 Pages; ManufacturerPanasonic; Websitehttp://www.panasonic.co.jp/semicon/e-index.html; Environmental Compliance

Download Datasheet Parametric View All

ECWF6273JLB Overview

Film Capacitor, Polypropylene, 630V, 5% +Tol, 5% -Tol, 0.027uF, Through Hole Mount, 5126, RADIAL LEADED

ECWF6273JLB Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	FLAME PROOF
capacitance	0.027 µF
Capacitor type	FILM CAPACITOR
dielectric materials	POLYPROPYLENE
high	14.5 mm
JESD-609 code	e3
length	13 mm
Installation features	THROUGH HOLE MOUNT
negative tolerance	5%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package shape	RECTANGULAR PACKAGE
Package form	Radial
method of packing	BULK
positive tolerance	5%
Rated (DC) voltage (URdc)	630 V
surface mount	NO
Terminal surface	Tin (Sn)
Terminal pitch	7.5 mm
Terminal shape	WIRE
width	6.6 mm
Base Number Matches	1
