BD9786KN
Regulators
System Regulator for HDD
BD9786KN
BD9786KN is an IC included a 2 channel switching regulator and P channel series regulator controller and reset circuit.
The switching regulator enables high efficiency because of a PFM control method. It is also built in a switching
component, Nch FET.
Applications
HDD, PDA
External dimensions
(Unit : mm)
Features
1) 2-ch switching regulator, P-channel series regulator controller
and reset circuit are built-in and recommendable for HDD.
2) High efficiency for PFM and synchronous rectification.
3) Built-in dual N-channel MOSFET switches.
4) Under voltage lockout, output short protection.
5) Built-in soft start circuit.
QFN28V
Absolute maximum rating
(Ta=25°C)
Parameter
Supply voltage
Power dissipation
Operating temperature range
Storage temperature range
Symbol
V
CC
Pd
Topr
Tstg
Limits
7
580
∗
Unit
V
mW
˚C
˚C
−25
to + 85
−55
to
+
125
∗
Derating in done 5.8mW/°C for operating above Ta
>
25˚C.
=
Recommended operating conditions
(Ta=25°C)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Supply voltage
V
CC
3.0
5.0
6.0
V
1/2
