ChipInductors–0603CTSeries(1608)
• Very low profile – only 60% of the height of our other 0603
inductor series
• Excellent Q, low DCR and very high SRF
Designer’s Kit C423
contains 10 each of all 5% values
and
Designer’s Kit C423-2
contains 10 each of all
2% values.
SRF
typ
5
(GHz)
16.0
16.0
12.0
11.0
11.0
10.7
7.00
7.00
6.30
6.30
5.60
5.50
5.05
4.50
4.50
4.25
3.95
3.95
4.00
3.50
3.30
3.10
2.95
2.90
2.75
2.70
2.55
2.45
2.20
2.30
2.25
2.10
1.90
1.85
1.75
Part number
1
0603CT-1N0XJL_
0603CT-1N2XJL_
0603CT-2N0XJL_
0603CT-2N3XJL_
0603CT-2N5XJL_
0603CT-3N0X_L_
0603CT-3N3X_L_
0603CT-3N6X_L_
0603CT-3N9X_L_
0603CT-4N3X_L_
0603CT-4N7X_L_
0603CT-5N1X_L_
0603CT-5N6X_L_
0603CT-6N8X_L_
0603CT-7N2X_L_
0603CT-8N2X_L_
0603CT-9N5X_L_
0603CT-10NX_L_
0603CT-11NX_L_
0603CT-12NX_L_
0603CT-15NX_L_
0603CT-16NX_L_
0603CT-18NX_L_
0603CT-20NX_L_
0603CT-22NX_L_
0603CT-24NX_L_
0603CT-27NX_L_
0603CT-30NX_L_
0603CT-33NX_L_
0603CT-36NX_L_
0603CT-39NX_L_
0603CT-43NX_L_
0603CT-47NX_L_
0603CT-51NX_L_
0603CT-56NX_L_
Inductance
2
(nH)
1.0
1.2
2.0
2.3
2.5
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.8
7.2
8.2
9.5
10
11
12
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
Percent
tolerance
3
5
5
5
5
5
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
900 MHz
L typ
Q typ
4
0.98
1.18
1.98
2.27
2.48
2.96
3.27
3.58
3.87
4.26
4.66
5.12
5.60
6.78
7.19
8.18
9.52
10.0
11.0
12.0
15.2
16.3
18.1
20.2
22.4
24.4
27.4
30.5
34.0
37.2
40.3
44.5
48.2
53.0
59.4
39
35
46
55
52
57
60
69
68
58
50
68
67
60
65
60
63
67
66
68
65
63
66
67
60
61
62
62
55
61
60
57
55
55
54
1.7 GHz
L typ
Q typ
4
0.99
1.19
1.98
2.28
2.50
2.97
3.33
3.63
3.95
4.34
4.75
5.18
5.73
7.00
7.44
8.46
9.92
10.4
11.5
12.7
16.1
17.5
19.2
21.6
24.3
26.5
29.8
33.9
39.1
42.3
45.3
51.3
57.8
63.2
75.4
58
50
70
81
77
82
83
95
90
84
70
93
90
81
88
78
80
85
86
85
80
76
80
80
70
72
75
73
61
63
65
60
57
55
48
DCR
max
6
(Ohms)
0.045
0.105
0.034
0.046
0.060
0.039
0.039
0.044
0.050
0.076
0.120
0.050
0.058
0.080
0.047
0.075
0.092
0.075
0.110
0.130
0.145
0.175
0.200
0.175
0.220
0.240
0.270
0.330
0.330
0.335
0.400
0.440
0.540
0.570
0.700
Irms
7
(mA)
1600
1100
1900
1600
1300
1600
1600
1600
1400
1300
960
1400
1300
1200
1500
1300
1100
1300
1000
920
800
760
720
760
700
680
670
600
600
600
570
530
470
440
420
1. When ordering, please specify
tolerance
and
packaging
codes:
0603CT-56NXGLW
Tolerance: G
= 2%
J
= 5% (Table shows stock tolerances in bold.)
Packaging: W
= 7″ machine-ready reel. EIA-481 punched paper tape
(2000 parts per full reel).
U
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter W instead.
2. Inductance measured at 250 MHz, 0.1 Vrms, 0 Adc using Coilcraft SMD-
A fixture in Agilent/HP 4287A impedance analyzer.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using Agilent/HP4291A with Agilent/HP 16193 test fixture.
5. SRF measured using Agilent/HP 8722ES network analyzer and Coilcraft
SMD-D test fixture.
6. DCR measured on Cambridge Technology micro-ohmmeter and
Coilcraft CCF858 test fixture.
7. Current that causes a 15°C temperature rise from 25°C ambient.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 485-1
Revised 10/03/08
© Coilcraft, Inc. 2009
Document 485-2
0603CT Series (1608)
Typical L vs Frequency
100
90
80
56 nH
Typical Q vs Frequency
100
90
80
70
39 nH
5.6 nH
10 nH
18 nH
27 nH
Inductance (nH)
70
Q Factor
60
50
40
30
20
10
0
1
10
100
1000
10000
27 nH
18 nH
10 nH
5.6 nH
39 nH
60
50
40
30
20
10
0
1
10
100
1000
10000
56 nH
Frequency (MHz)
Frequency (MHz)
Typical Irms Derating
120
110
100
Designer’s Kit C423
contains 10 each of all 5% values;
Designer’s Kit C423-2
contains 10 each of all 2% values
Core material
Ceramic
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
160 – 190 mg
Ambient temperature
–40°C to +125°C with
Irms
current, +125°C
to +140°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +125 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Percent of rated
I
rms
90
80
70
60
50
40
30
20
10
0
-40
-20
0
20
40
60
80
100
120 140
25°C
Ambient temperature (°C)
B
overall
D
A
D
E
terminal
Packaging
2000/7″reel; Paper tape: 8 mm wide, 0.68 mm thick,
4 mm pocket spacing
PCB washing
Only pure water or alcohol recommended
C
G
F
G
H
Terminal wraparound:
approx 0.006/0,15 both ends
Recommended
Land Pattern
G
0.025
0,64
H
0.040 inches
1,02 mm
A max B max
0.064
1,63
0.033
0,84
C max
0.024
0,61
D
0.013
0,33
E
0.030
0,76
F
0.025
0,64
Specifications subject to change without notice.
Please check our website for latest information.
Document 485-2
Revised 10/03/08
© Coilcraft, Inc. 2009
