Document 100-1
Chip Inductors – 0805CS Series (2012)
• Exceptional Q values, even at high frequencies
• Tight tolerances – 2% for most; 1% for some values
Part number
1
• Wirewound construction provides the highest SRFs in 0805
size
SRF typ
5
(MHz)
12200
12200
12200
5900
5600
4800
4400
4300
4000
3200
3100
2600
2400
2580
2150
1900
2000
1800
1700
1600
1500
1330
1330
1250
1100
1100
920
920
820
770
730
650
600
375
330
310
310
Inductance
2
(nH)
2.8 @
3.0 @
3.3 @
5.6 @
6.8 @
7.5 @
8.2 @
10 @
12 @
15 @
18 @
22 @
24 @
27 @
33 @
36 @
39 @
43 @
47 @
56 @
68 @
82 @
91 @
100 @
110 @
120 @
150 @
180 @
220 @
240 @
270 @
330 @
390 @
470 @
560 @
680 @
820 @
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
200 MHz
200 MHz
200 MHz
200 MHz
150 MHz
150 MHz
150 MHz
150 MHz
150 MHz
100 MHz
100 MHz
100 MHz
100 MHz
100 MHz
100 MHz
100 MHz
50 MHz
25 MHz
25 MHz
25 MHz
Percent
tolerance
3
5
5
5
5
5
5
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2
5,2,1
5,2,1
5,2,1
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
Q min
80 @
65 @
50 @
65 @
50 @
50 @
50 @
60 @
50 @
50 @
50 @
55 @
50 @
55 @
60 @
55 @
60 @
60 @
60 @
60 @
60 @
65 @
65 @
65 @
50 @
50 @
50 @
50 @
50 @
44 @
48 @
48 @
48 @
33 @
23 @
23 @
23 @
4
DCR max
6
(Ohms)
0.06
0.06
0.08
0.08
0.11
0.14
0.12
0.10
0.15
0.17
0.20
0.22
0.22
0.25
0.27
0.27
0.29
0.34
0.31
0.34
0.38
0.42
0.48
0.46
0.48
0.51
0.56
0.64
0.70
1.00
1.00
1.40
1.50
1.76
1.90
2.20
2.35
Irms
7
(mA)
800
800
600
600
600
600
600
600
600
600
600
500
500
500
500
500
500
500
500
500
500
400
400
400
400
400
400
400
400
350
350
310
290
250
230
190
180
Color
code
Gray
White
Black
Orange
Brown
Green
Red
Blue
Orange
Yellow
Green
Blue
Gray
Violet
Gray
Orange
White
Yellow
Black
Brown
Red
Orange
Black
Yellow
Brown
Green
Blue
Violet
Gray
Red
White
Black
Brown
Violet
Orange
Green
Blue
0805CS-020XJL_
0805CS-3N0XJL_
0805CS-030XJL_
0805CS-050XJL_
0805CS-060XJL_
0805CS-070XJL_
0805CS-080X_L_
0805CS-100X_L_
0805CS-120X_L_
0805CS-150X_L_
0805CS-180X_L_
0805CS-220X_L_
0805CS-240X_L_
0805CS-270X_L_
0805CS-330X_L_
0805CS-360X_L_
0805CS-390X_L_
0805CS-430X_L_
0805CS-470X_L_
0805CS-560X_L_
0805CS-680X_L_
0805CS-820X_L_
0805CS-910X_L_
0805CS-101X_L_
0805CS-111X_L_
0805CS-121X_L_
0805CS-151X_L_
0805CS-181X_L_
0805CS-221X_L_
0805CS-241X_L_
0805CS-271X_L_
0805CS-331X_L_
0805CS-391X_L_
0805CS-471X_L_
0805CS-561X_L_
0805CS-681X_L_
0805CS-821X_L_
1500 MHz
1500 MHz
1500 MHz
1000 MHz
1000 MHz
1000 MHz
1000 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
100 MHz
50 MHz
50 MHz
50 MHz
1. When ordering, specify
tolerance, termination
and
packaging
codes:
0805CS-821XGL
C
L
F
= 1%
G
= 2%
J
= 5%
(Table shows stock tolerances in bold.)
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging:
C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked (7500 parts
per full reel).
Tolerance:
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/
HP 4286A impedance analyzer with Coilcraft-provided correlation
pieces.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using an Agilent/HP 4291A with an Agilent/HP 16193 test
fixture.
5. SRF measured using an Agilent/HP 8720D network analyzer and a
Coilcraft SMD-D test fixture.
6. DCR measured on a Cambridge Technology micro-ohmmeter and a
Coilcraft CCF858 test fixture.
7. Current that causes a 15°C temperature rise from 25°C ambient.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 100-1
Revised 10/06/08
© Coilcraft, Inc. 2009
Document 100-2
0805CS Series (2012)
Typical Q vs Frequency
100
90
80
68 nH
6.8 nH
39 nH
Typical L vs Frequency
12 nH
22 nH
1000
3.3 nH
220 nH
Inductance (nH)
70
120 nH
100
100 nH
39 nH
15 nH
Q Factor
60
50
40
30
20
10
0
10
100
1000
10,000
270 nH
10
3.3 nH
1
10
100
1000
Frequency (MHz)
Frequency (MHz)
Designer’s Kit C303
contains 10 of each 5% part
Designer’s Kit C303-2
contains 10 of each 2% part
Core material
Ceramic
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
10.2 – 11.6 mg
Ambient temperature
–40°C to +125°C with
Irms
current, +125°C
to +140°C with derated current
Storage temperature
Component: –40°C to +140°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+100 to +250 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Irms Derating
120
110
100
Percent of rated
I
rms
90
80
70
60
50
40
30
20
10
0
-40
-20
0
20
40
60
80
100
120 140
25°C
Ambient temperature (°C)
B
overall
F
A
G
F
E
terminal
D
Terminal wraparound:
approx 0.015/0,38 both ends
Packaging
2000 per 7″ reel; 7500 per 13″ reel. Plastic tape: 8 mm wide,
0.23 mm thick, 4 mm pocket spacing, 1.65 mm pocket depth
PCB washing
Only pure water or alcohol recommended
C
I
J
I
H
Recommended
Land Pattern
H
I
J
A
max
B
max
C
max
D
ref
E
F
G
0.090 0.068 0.060 0.020 0.050 0.020 0.040 0.070 0.040 0.030 inches
2,29
1,73
1,52
0,51
1,27
0,51
1,02
1,78
1,02
0,76 mm
Specifications subject to change without notice.
Please check our website for latest information.
Document 100-2
Revised 10/06/08
© Coilcraft, Inc. 2009
