DF005S thru DF10S
SINGLE-PHASE GLASS PASSIVATED SMD BRIDGE RECTIFIERS
VOLTAGE - 50 TO 1000 VOLTS
CURRENT - 1.0 AMPERES
8.5
8.1
FEATURES
Glass passivated JUNCTION
Surge overload rating to 50 amperes peak
Ldeal for printed circuit board applications
Low Forward Voltage drop
Reliable low cost construction utilizing molded
Plastic technique
Plastic PACKAGE HAS underwriters Laboratory
Flammability Classification 94V-0
High temperature soldering guaranteed
260
o
C/10seconds at 5lbs. (2.3kg) tension
MECHANICAL DATA
Case Molded plastic body over passivated junction
Terminals Plated lead, solderable per
MIL-STD-202, Method 208
Polarity Polarity symbols marked on body
Weight 0.04 ounce, 1.0gram
MAXIMUM RATIXGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temp. unless otherwise specified
Single phase, half sine wave, 60Hz, resistive or inductive load
For capacitive load, derate current by 20%
SYMBOL DF005S DF01S DF02S DF04S DF06S DF08S DF10S
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current @ T
A
=40
0
C
Peak Forward Surge Current, 8.3ms Single Half Sine-Wave
Superimposed on Rated Load
Maximum Instantaneous Forward Voltage Drop per Bridge
Element at 1.0A
Maximum DC Reverse @T
A
=25
0
C
at rated DC Blocking Voltage @T
A
=125
0
C
Rating for fusing (t<8.3ms)
Typical Junction capacitance (Note 1)
Typical Thermal resistance (Note 2)
Operating and Storage Temperature Range
V
RRM
V
RMS
V
DC
V
(AV)
I
FSM
50
35
50
100
70
100
200
140
200
400
280
400
1.0
50
600
420
600
800
560
800
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
Amps
V
F
1.1
10
500
10.4
25
74
0
Volts
I
R
I t
C
J
R
JC
2
A
AS
pF
C/W
0
2
T
J
T
STG
-55 to +150
C
NOTES
1. Measured at 1.0 MHz and Applied Reverse Voltage of 4.0 Volts
2. Thermal Resestance From Junction to Ambient mounted on P
.C.B with 0.5 x 0.5
(13x13mm) copper pads
www.paceleader.tw
1
DF005S thru DF10S
SINGLE-PHASE GLASS PASSIVATED BRIDGE RECTIFIERS
RATING AND CHARACTERISTICS CURVES DF005S THRU DF10S
Fig. 1
-
MAXIMUM FORWARD SURGE CURRENT
PEAK FORWARD SURGE CURRENT
AMPERES
60
50
40
30
Fig. 2
-
DERATING CURVE
OUTPUT RECTIFIED CURRENT
1.6
1.4
BRIDGE OUTPUT
FULL WAVE RECTIFIED CURRENT
AVERAGE AMPERES
1.2
1.0
TJ=25 C
20
0
.8
10
.6
.4
0
1
10
100
NUMBER OF CYCLES AT 60 Hz
.2
0
20
40
60
80
100
120
140
AMBIENT TEMPERATURE,
0
C
Fig. 3 - TYPICAL FORWARD
CHARACTERISTICS
10
TJ=25 C
0
Fig. 4
-
TYPICAL REVERSE
CHARACTERISTICS
10
INSTANTANEOUS FORWARD CURRENT, AMPERES
INSTANTANEOUS REVERSE
CURRENT, MICROAMPERES
TYPICAL
DISTRIBUTION
1.0
1.0
TJ=25
0
C
0.1
0.1
.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK
REVERSE VOLTAGE
.01 0.4
0.6
0.8
1.0
1.2
1.4
INSTANTANEOUS FORWARD VOLT
AGE, VOLTS
www.paceleader.tw
2
