Document 219-1
Power Chip Inductors – 1008PS Series
• Shielded power chip inductors
• Excellent current handling for a part this size
For new designs, we recommend the LPS4018 as an
alternative to this series. The LPS4018 series offers a
significantly lower profile and much lower DCR. We will
continue to manufacture and support the 1008PS.
Inductance
Part
±10%
2
Q
1
number
(µH)
min
3
1008PS-102KL_
1.0
35
1008PS-152KL_
1.5
35
1008PS-182KL_
1.8
35
1008PS-222KL_
2.2
36
1008PS-272KL_
2.7
38
1008PS-332KL_
3.3
26
1008PS-392KL_
3.9
38
1008PS-472KL_
4.7
38
1008PS-562KL_
5.6
38
1008PS-682KL_
6.8
38
1008PS-103KL_
10
38
1008PS-153KL_
15
38
1008PS-223KL_
22
40
1008PS-333KL_
33
45
1008PS-393KL_
39
45
1008PS-473KL_
47
45
1008PS-683KL_
68
45
1008PS-823KL_
82
45
1008PS-104KL_ 100
45
1008PS-124KL_ 120
50
1008PS-154KL_ 150
50
1008PS-224KL_ 220
55
1008PS-334KL_ 330
55
1008PS-474KL_ 470
55
1008PS-564KL_ 560
55
1008PS-684KL_ 680
55
1008PS-824KL_ 820
45
1008PS-105KL_ 1000
45
DCR
4
max
(Ohms)
0.05
0.06
0.09
0.10
0.14
0.84
0.26
0.35
0.36
0.58
0.92
1.15
1.40
1.61
1.85
2.5
3.8
4.3
5.8
6.3
7.5
10.0
11.5
16.3
18.1
24.0
26.0
29.0
SRF
5
typ
(MHz)
387
276
253
228
207
199
185
160
150
120
105
35
26
20
16
19
12
9.0
7.0
7.0
5.8
5.0
3.8
3.1
2.8
2.5
1.5
2.0
Isat
(A)
6
10% 20% 30%
drop drop drop
3.5
3.9
4.2
2.7
3.2
3.5
2.3
2.7
3.0
2.4
2.8
3.1
1.6
2.0
2.3
1.5
1.6
1.6
1.5
1.8
2.0
1.3
1.6
1.7
1.5
1.7
1.8
1.3
1.5
1.6
0.84 1.0
1.1
0.81 0.87 0.90
0.67 0.75 0.79
0.53 0.61 0.68
0.49 0.56 0.60
0.47 0.52 0.54
0.38 0.42 0.45
0.33 0.38 0.42
0.35 0.38 0.39
0.30 0.33 0.35
0.27 0.30 0.33
0.21 0.24 0.27
0.19 0.21 0.23
0.14 0.17 0.19
0.13 0.15 0.17
0.11 0.15 0.17
0.10 0.12 0.13
0.11 0.13 0.14
Irms
(A)
7
20°C 40°C
rise rise
1.4
2.0
1.4
2.0
0.98 1.4
1.2
1.7
1.0
1.4
0.51 0.67
0.82 1.1
0.70 0.95
0.66 0.87
0.45 0.76
0.40 0.59
0.36 0.51
0.33 0.44
0.30 0.42
0.28 0.39
0.23 0.31
0.21 0.26
0.18 0.26
0.16 0.20
0.14 0.20
0.13 0.18
0.13 0.17
0.11 0.15
0.10 0.13
0.093 0.12
0.073 0.11
0.073 0.10
0.070 0.10
1. When ordering, specify
termination
and
packaging
codes:
1008PS-105KLC
Termination: L
= RoHS compliant silver-palladium-
platinum-glass frit.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: C=
7″ machine-ready reel. EIA-481
embossed plastic tape (750 parts per full
reel).
B=
Less than full reel. In tape, but not
machine ready. To have a leader and
trailer added ($25 charge), use code
letter C instead.
D=
13″ machine-ready reel. EIA-481
embossed plastic tape. Factory order
only, not stocked (2500 parts per full
reel).
2. Inductance measured at 100 kHz, 0.1 Vrms, using
Coilcraft SMD-A fixture in Agilent/HP 4263B impedance
analyzer or equivalent.
3. Q measured at 1 MHz using an Agilent/HP 16193 test
fixture and an Agilent/HP 4291 or equivalent.
4. DCR measured on micro-ohmmeter and Coilcraft CCF840
test fixture.
5. SRF measured using a Coilcraft SMD-D test fixture and
an Agilent/HP 8753D network analyzer or equivalent.
6. DC current at which the inductance drops the specicfied
amount from its value without current.
7. Current that causes the specified temperature rise from
25°C ambient.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 219-1
Revised 08/17/09
© Coilcraft, Inc. 2009
Document 219-2
Power Chip Inductors – 1008PS Series
Typical L vs Frequency
10000
1000 µH
Typical L vs Current
10000
1000 µH
1000
1000
Inductance (µH)
Inductance (µH)
100
100 µH
100
100 µH
10
10 µH
10
10 µH
1
1 µH
1
1 µH
0.1
0.01
0.1
1
10
0.1
0.01
0.1
1
10
Frequency (MHz)
B
F
Current (A)
C
D
Irms Derating
120
110
100
A
H
I
E
G
J
I
Percent of rated
I
rms
90
80
70
60
50
40
30
20
10
0
-40
-20
0
20
40
60
80
100
120
140 160
25°C
A
max
3,81
B
max
3,78
C
max
2,74
D
max
1,78
E
max
2,59
F
max
G
typ
H
Terminal wraparound:
approx 0.015/0,38 both ends
Recommended
Land Pattern
I
J
inches
mm
0.150 0.149 0.108 0.070 0.102 0.084 0.020 0.100 0.040 0.050
2,13 0,51
2,54 1,02 1,27
Ambient temperature (°C)
Core material
Ceramic/Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
122 – 132 mg
Ambient temperature
–40°C to +105°C with
Irms
current, +105°C
to +145°C with derated current
Storage temperature
Component: –40°C to +145°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+100 to +350 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
750/7″reel; 2500/13″ reel Plastic tape: 12 mm wide,
0.3 mm thick, 8 mm pocket spacing, 3.3 mm pocket depth
PCB washing
Only pure water or alcohol recommended
Specifications subject to change without notice.
Please check our website for latest information.
Document 219-2
Revised 08/17/09
© Coilcraft, Inc. 2009
