AA04104R7KL Overview

AXIAL INDUCTOR

SPECIFICATION FOR APPROVAL
REF : 20080714-B
PROD.
NAME
ABC'S DWG NO.
AA0410□□□□L□-□□□
PAGE: 1
AXIAL INDUCTOR
ABC'S ITEM NO.
Ⅰ﹒CONFIGURATION
& DIMENSIONS:
A :
B :
C :
D :
ψ
W :
4.0 max.
10.5 max.
61.0 ref.
25.4 min.
0.65
m/m
m/m
m/m
m/m
m/m
D
B
C
※Color
code
1st Color:First Significant Figure
2nd Color:Second Significant Figure
3rd Color:Muliplier
4th Color:Tolerance
Ⅱ﹒SCHEMATIC
DIAGRAM:
A
b
a
Ⅲ﹒MATERIALS:
a﹒Core:Ferrite DR core
b﹒Wire:Enamelled copper wire ( class B )
c﹒Terminal:Cu/Ni/Sn
d﹒Coating: Epoxy resin
e﹒Remark:Products comply with RoHS' requirements
d
c
Ⅳ﹒GENERAL
SPECIFICATION:
a﹒Temp. rise:20℃ max.
b﹒Ambient temp:60℃ max.
c﹒Operating temp:-55℃---- 105℃
d﹒Terminal tensile strength:2.5 KG min
e﹒Terminal bending strength:0.5 KG min
f﹒Dielectric withstanding voltage:500 Vrms
g﹒Rated current:Base on temp rise
AR-001A
