B82732F datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> B82732F

B82732F: Description250 V, 50/60 HZ, SINGLE PHASE EMI FILTER; CategoryPassive components; File Size640KB，6 Pages; ManufacturerEPCOS (TDK)

Download Datasheet Parametric Compare View All

B82732F Overview

250 V, 50/60 HZ, SINGLE PHASE EMI FILTER

B82732F Parametric

Parameter Name	Attribute value
working frequency	50/60 HZ
Processing package description	ROHS COMPLIANT PACKAGE
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	ACTIVE
Installation type	Through hole/solder mounting
terminal coating	Tin OVER Nickel
Dimensions	L24.5XB14.5XH13.5 (mm)/L0.965XB0.571XH0.531 (inch)
Manufacturer Series	B82732F
filter type	Single Phase EMI Filter
Rated current	1.3 A
Rated voltage	250 V

Preview

Download Datasheet

View All

Power line chokes

Current-compensated frame core double chokes

250 V AC, 0.45 … 1.6 A, 10 … 100 mH, +40 °C

Series/Type:

Date:

B82732F

June 2013

a~í~=pÜÉÉí



EPCOS AG 2015. Reproduction, publication and dissemination of this publication, enclosures hereto and the information

contained therein without EPCOS' prior express consent is prohibited.

EPCOS AG is a TDK Group Company.

Cautions and warnings

■

Please note the recommendations in our Inductors data book (latest edition) and in the data

sheets.

– Particular attention should be paid to the derating curves given there. Derating must be applied

in case the ambient temperature in the application exceeds the rated temperature of the

component.

– Ensure the operation temperature (which is the sum of the ambient temperature and the

temperature rise caused by losses / self-heating) of the component in the application does not

exceed the maximum value specified in the climatic category.

– The soldering conditions should also be observed. Temperatures quoted in relation to wave

soldering refer to the pin, not the housing.

■

If the components are to be washed varnished it is necessary to check whether the washing

varnish agent that is used has a negative effect on the wire insulation, any plastics that are used,

or on glued joints. In particular, it is possible for washing varnish agent residues to have a

negative effect in the long-term on wire insulation.

Washing processes may damage the product due to the possible static or cyclic mechanical

loads (e.g. ultrasonic cleaning). They may cause cracks to develop on the product and its parts,

which might lead to reduced reliability or lifetime.

■

The following points must be observed if the components are potted in customer applications:

– Many potting materials shrink as they harden. They therefore exert a pressure on the plastic

housing or core. This pressure can have a deleterious effect on electrical properties, and in

extreme cases can damage the core or plastic housing mechanically.

– It is necessary to check whether the potting material used attacks or destroys the wire

insulation, plastics or glue.

– The effect of the potting material can change the high-frequency behaviour of the components.

■

Ferrites are sensitive to direct impact. This can cause the core material to flake, or lead to

breakage of the core.

■

Even for customer-specific products, conclusive validation of the component in the circuit can

only be carried out by the customer.

Please read

Cautions and warnings

and

Important notes

at the end of this document.

06/13

B82732F Related Products

	B82732F	B82732F2132B001	B82732F2451B001	B82732F2162B001
Description	250 V, 50/60 HZ, SINGLE PHASE EMI FILTER	250 V, 50/60 HZ, SINGLE PHASE EMI FILTER	250 V, 50/60 HZ, SINGLE PHASE EMI FILTER	250 V, 50/60 HZ, SINGLE PHASE EMI FILTER
working frequency	50/60 HZ	50/60 HZ	50/60 HZ	50/60 HZ
Processing package description	ROHS COMPLIANT PACKAGE	ROHS COMPLIANT PACKAGE	ROHS COMPLIANT PACKAGE	ROHS COMPLIANT PACKAGE
Lead-free	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes
China RoHS regulations	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Installation type	Through hole/solder mounting	Through hole/solder mounting	Through hole/solder mounting	Through hole/solder mounting
terminal coating	Tin OVER Nickel	Tin OVER Nickel	Tin OVER Nickel	Tin OVER Nickel
Dimensions	L24.5XB14.5XH13.5 (mm)/L0.965XB0.571XH0.531 (inch)	L24.5XB14.5XH13.5 (mm)/L0.965XB0.571XH0.531 (inch)	L24.5XB14.5XH13.5 (mm)/L0.965XB0.571XH0.531 (inch)	L24.5XB14.5XH13.5 (mm)/L0.965XB0.571XH0.531 (inch)
Manufacturer Series	B82732F	B82732F	B82732F	B82732F
filter type	Single Phase EMI Filter	Single Phase EMI Filter	Single Phase EMI Filter	Single Phase EMI Filter
Rated current	1.3 A	1.3 A	1.3 A	1.6 A
Rated voltage	250 V	250 V	250 V	250 V
