SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 1
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB1305□□□□L□-□□□
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A
A : 12.70±0.3
B : 12.70±0.3
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
6R8
B
C :
D :
E :
F :
G :
G
I :
J :
I
4.80±0.3
3.00 typ
2.00 typ
8.60 typ
3.60 ref.
2.60 ref.
8.40 ref.
C
H : 13.60 ref.
D
E
F
E
Ⅱ﹒SCHEMATIC
DIAGRAM：
（PCB
Pattern）
I
H
J
a
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Wire
：Enamelled
copper wire
（class
F）
c﹒Base：LCP E4008
d﹒Terminal
：Cu/Sn
e﹒Adhesive：Epoxy resin
f﹒Remark：Products comply with RoHS'
requirements
250
Temperature (
℃
)
Peak Temp：260℃ max.
Max time above 230℃
：50sec
max.
Max time above 200℃
：70sec
max.
Temperature
Rising Area
+4.0
℃
/ sec max.
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
b
c
e
d
Reflow Area
+2.0 ~ 4.0
℃
/ sec max.
Forced Cooling Area
-(1.0 ~ 5.0)
℃
/ sec max.
Peak Temperature:
260
℃
50sec max.
230
℃
Ⅳ﹒GENERAL
SPECIFICATION：
a﹒Temp. rise 40℃ max.
b﹒Storage Temp.：-40℃ ----+125℃
c﹒Operating Temp.：-40℃----+125℃
（Temp.
rise included）
d﹒Resistance to solder heat
：260℃.10
secs.
AE-001A
200
150
70sec max.
100
50
0
50
100
150
Time ( seconds )
200
250
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 2
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB1305□□□□L□-□□□
Ⅴ﹒ELECTRICAL
CHARACTERISTICS：
L
DWG No.
(uH)
SB13052R5YL□-□□□
SB13053R5YL□-□□□
SB13054R6YL□-□□□
SB13056R8YL□-□□□
SB1305100ML□-□□□
SB1305150ML□-□□□
SB1305220ML□-□□□
SB1305330ML□-□□□
SB1305470ML□-□□□
SB1305680ML□-□□□
SB1305101KL□-□□□
SB1305151KL□-□□□
SB1305221KL□-□□□
SB1305331KL□-□□□
SB1305471KL□-□□□
SB1305681KL□-□□□
SB1305102KL□-□□□
2.5±25%
3.5±25%
4.6±25%
6.8±25%
10.0±20%
15.0±20%
22.0±20%
33.0±20%
47.0±20%
68.0±20%
100.0±10%
150.0±10%
220.0±10%
330.0±10%
470.0±10%
680.0±10%
1000.0±10%
Q
ref.
20
18
20
18
25
25
26
22
20
20
18
15
15
10
10
10
32
Test Freq.
L
Q
(Hz)
(MHz)
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
100K/10mV
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.252
SRF
( MHz )
typ.
61.0
43.0
35.0
32.0
27.0
24.0
20.0
16.0
13.0
11.0
11.0
8.0
7.0
6.0
4.0
3.5
2.7
RDC
( mΩ )
max.
14
16
18
24
37
46
62
85
130
165
255
380
500
700
1150
1400
2350
Irms
(A)
7.20
6.00
5.20
4.30
3.60
3.30
2.90
2.50
1.90
1.65
1.40
1.20
1.00
0.85
0.67
0.60
0.46
Isat
(A)
8.00
7.00
6.00
5.20
4.40
3.70
3.00
2.60
2.00
1.80
1.40
1.15
0.95
0.80
0.70
0.58
0.47
1).
□：Packaging
Information… A：Bulk B：Taping Reel
2)."-
□□□
":Reference code
10
4
3). Irms base on temp. rise 40
℃
max.
4). Isat base on
△
L/L0A=25% typ.
@ Inductance VS. DC Superposition Characteristics
10
Inductance ( uH )
3
331
10
2
101
330
10
1
100
3R5
10
0
10
-1
10
10
DC Current ( A )
0
1
10
2
AE-001A
REF :
PROD.
NAME
SPECIFICATION FOR APPROVAL
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB1305□□□□L□-□□□
PAGE: 3
Ⅵ﹒PACKAGING
INFORMATION：
( 1 ) Configuration
T
Cover Tape
2.0±0.5
A
B
N
∮
C
∮
C
G
D
Embossed Carrier
※
Carrier Tape Width : D
P:16 m/m
4 m/m
End
Start
6R8
6R8
6R8
6R8
6R8
Leader
no component
200 m/m min.
Components
User direction of feed
Trailer
no component
400 m/m min.
( 2 ) Dimensions
Style
13 - 24
A
330
B
21±0.8
C
13
D
24
G
26
+0
N
50
-0
Unit:m/m
T
30.4
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SB1305
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
600
1,430
13 - 24
2,400
6.8
40 x 40 x 24
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 4
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB1305□□□□L□-□□□
Ⅶ﹒DWGING
NUMBER EXPRESSION：
S
B
1
3
0
5
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
T.B.D.
Inner package
Inner package Q'TY
T.B.D.
600
pcs
Remark
T / R ( Reel package )
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 5
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB1305□□□□L□-□□□
Ⅷ﹒RELIABILITY
TEST：
Test item
Specification
More than 90% of the
terminal electrode
Shall be covered
With fresh solder.
Test condition
Preheat : 150±25
℃
for 60 seconds
Solder : Sn96.5 / Ag3 / Cu0.5 or equivalent
Solder temp. : 235±5℃
Flux : Rosin
Dip time : 4±1 seconds
Solderability
Thermal shock test
( Temp. cycle )
Inductance shall
not change more
than ±20%
Room temp.
15 minutes
Room temp.
15 minutes
Total : 50 cycles
-25±2
℃
30 minutes
85±2
℃
30 minutes
Humidity
Resistance test
Temperature : 40±2℃
Humidity : 90 ~ 95%
Applied current : Per spec.
Time : 500 hours
High temp.
Resistance test
Temperature : 85±2℃
Applied current : Per spec.
Time : 500 hours
AE-001A
