SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 1
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB2206□□□□L□-□□□
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A
A : 22.0 ±0.3
B : 15.0 ±0.3
C :
6.8 ±0.5
D : 15.0 (typ.)
E :
2.3 (typ.)
F :
8.0 (typ.)
m/m
m/m
m/m
m/m
m/m
m/m
121
Marking
white dot is start winding
& Inductance code
C
B
9.20
E
D
E
27.5
9.10
9.20
14.8
9.0
F
4.0
13.5
21.5
4.0
( PCB Pattern )
Ⅱ﹒SCHEMATIC
DIAGRAM：
a
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Wire：Enamelled copper wire
（class
F）
c﹒Base：Hitachi phenolic CP-J-8700
d﹒Adhesive：Epoxy resin
e﹒Terminal：Cu/Sn
f﹒Remark：Products comply with RoHS'
requirements
Temperature (
℃
)
250
50sec max.
b
Peak Temp：260℃ max.
Max time above 230℃
：50sec
max.
Max time above 200℃
：70sec
max.
Temperature
Rising Area
+4.0
℃
/ sec max.
d
c
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
Reflow Area
+2.0 ~ 4.0
℃
/ sec max.
Forced Cooling Area
-(1.0 ~ 5.0)
℃
/ sec max.
Peak Temperature:
260℃
230℃
Ⅳ﹒GENERAL
SPECIFICATION：
a﹒Temp. rise： 40℃ max.
b﹒Storage temp.：-40℃ ~ +125℃
c﹒Operating temp.：-40℃ ~ +105℃
d﹒Resistance to solder heat
：260℃.
10 secs.
AE-001A
200
150
70sec max.
100
50
0
50
100
150
Time ( seconds )
200
250
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 2
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB2206□□□□L□-□□□
Ⅴ﹒ELECTRICAL
CHARACTERISTICS：
DWG NO.
SB2206121KL□-□□□
SB2206151KL□-□□□
SB2206181KL□-□□□
SB2206221KL□-□□□
SB2206271KL□-□□□
SB2206331KL□-□□□
SB2206391KL□-□□□
SB2206471KL□-□□□
SB2206561KL□-□□□
SB2206681KL□-□□□
SB2206821KL□-□□□
SB2206102KL□-□□□
Inductance
(µH)
0.1V/100KHz
120±10%
150±10%
180±10%
220±10%
270±10%
330±10%
390±10%
470±10%
560±10%
680±10%
820±10%
1000±10%
Q
ref.
20
19
17
19
22
20
21
25
23
25
25
25
SRF
(MHz)
nom.
5.00
4.87
4.65
3.97
3.37
3.15
3.00
2.55
2.40
2.50
1.97
1.60
RDC
(mΩ)
max.
230
250
300
380
470
560
680
850
1000
1100
1400
1800
Irms (A) max.
△
T = 40
℃
1.60
1.50
1.30
1.20
1.10
1.00
0.90
0.82
0.78
0.72
0.64
0.56
Ipk (A) typ.
△
L / L0A = 10%
3.0
2.6
2.5
2.4
2.2
1.9
1.7
1.4
1.3
1.2
1.1
1.0
1).
□：Packaging
information… A：Bulk
2). "-
":Reference code
3). Irms base on Temp. rise 40
℃
max.
4). Ipk base on
△
L/L0A=10% typ.
5). L,Q Test Frequency：100KHz / 0.1V
□□□
B：Taping Reel
@ Inductance VS. DC Current Curve
104
7
5
3
2
103
7
5
3
2
102K
（℃）
@ DC Current VS. Temp. Rise Curve
Inductance ( uH )
103
7
5
3
2
102
7
5
3
2
101
10-1
2
561K
271K
121K
102
7
5
3
2
101
7
5
3
2
102
561 271
121
3
5 7 100
2
3
5 7 101
2
3
5 7 102
100
100
2 3
5 7 101
2 3
5 7 102
2 3
5 7 103
DC Current ( A )
DC Current (A)
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 3
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB2206□□□□L□-□□□
Ⅵ﹒PACKAGING
INFORMATION：
1. Configuration :
T
Cover tape
2.0±0.5
A
B
∮
C
∮
C
N
G
Embossed carrier
※Carrier
tape width：D
P: 20m/m
End
28m/m
4 m/m
Start
Leader
no component
200 m/m min.
Components
User direction of feed
Trailer
no component
400 m/m min.
2. Dimensions : (m/m)
Style
13 - 32
A
330
B
21±0.8
C
13±0.5
D
32
G
34
+0
N
-0
100
T
38.4
3. Q'TY & G.W. Per package :
Inner : Reel
Series
SB2206
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (kg)
Size (cm)
250
1,250
13 - 32
1,000
6.8
40 x 40 x 24
AE-001A
D
121
121
121
121
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
ABC'S DWG NO.
PAGE: 4
SMD POWER INDUCTOR
SB2206□□□□L□-□□□
ABC'S ITEM NO.
Ⅶ﹒DWGING
NUMBER EXPRESSION：
S
B
2
2
0
6
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
Inner package
T.B.D.
T / R ( Reel package )
Inner package Q'TY
T.B.D.
250
pcs
Remark
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 5
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB2206□□□□L□-□□□
Ⅷ﹒RELIABILITY
TEST：
Test item
Specification
More than 90% of the
terminal electrode
Shall be covered
With fresh solder.
Test condition
Preheat : 150±25
℃
for 60 seconds
Solder : Sn96.5 / Ag3 / Cu0.5 or equivalent
Solder temp. : 235±5℃
Flux : Rosin
Dip time : 4±1 seconds
Solderability
Thermal shock test
( Temp. cycle )
Inductance shall
not change more
than ±20%
Room temp.
15 minutes
Room temp.
15 minutes
Total : 50 cycles
-25±2
℃
30 minutes
85±2
℃
30 minutes
Humidity
Resistance test
Temperature : 40±2℃
Humidity : 90 ~ 95%
Applied current : Per spec.
Time : 500 hours
High temp.
Resistance test
Temperature : 105±2℃
Applied current : Per spec.
Time : 500 hours
AE-001A
