SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 1
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB5014□□□□L□-□□□
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A
4
3
A : 5.60
B : 6.00
C
D
E
F
G
H
I
J
K
L
M
:
:
:
:
:
:
:
:
:
:
:
1.45
1.00
5.20
3.20
0.80
1.30
2.00
6.40
4.60
1.30
3.80
±0.3
±0.3
±0.1
typ.
typ.
typ.
ref.
ref.
ref.
ref.
ref.
ref.
ref.
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
100
1
2
C
B
D
G
D
H
I
H
L
E
F
K
( PCB Pattern Suggestion )
Ⅱ﹒SCHEMATIC
DIAGRAM：
1
3
L
M
a
b
d
Peak Temp：260℃ max.
Max time above 230℃
：50sec
max.
Max time above 200℃
：70sec
max.
Temperature
Rising Area
+4.0
℃
/ sec max.
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
Reflow Area
Forced Cooling Area
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Base：PCB Base FR4
c﹒Adhesive
：Epoxy
resin
d﹒Wire：Enamelled copper wire
（class
F）
e﹒Terminal：Cu/Ni/Au
f﹒Remark：Products comply with RoHS'
requirements
250
J
100
c
+2.0 ~ 4.0
℃
-(1.0 ~ 5.0)
℃
/ sec max.
/ sec max.
Peak Temperature:
260℃
50sec max.
230℃
a﹒Temp. rise
：40℃
typ.
b﹒Storage Temp.：-40℃ ----+125℃
c﹒Operating Temp.：-40℃----+125℃
( Temp. rise Included )
d﹒Resistance to solder heat
：260℃.10
secs.
AR-001A
Temperature (
℃
)
Ⅳ﹒GENERAL
SPECIFICATION：
200
150
70sec max.
100
50
0
50
100
150
Time ( seconds )
200
250
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 2
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB5014□□□□L□-□□□
Ⅴ﹒ELECTRICAL
CHARACTERISTICS
：
DWG No.
SB50141R0ML□-□□□
SB50142R2ML□-□□□
SB50143R3ML□-□□□
SB50144R7ML□-□□□
SB50146R8ML□-□□□
SB5014100ML□-□□□
SB5014150ML□-□□□
SB5014220ML□-□□□
SB5014330ML□-□□□
SB5014470ML□-□□□
SB5014680ML□-□□□
SB5014101ML□-□□□
Inductance
( µH )
1.0±20%
2.2±20%
3.3±20%
4.7±20%
6.8±20%
10.0±20%
15.0±20%
22.0±20%
33.0±20%
47.0±20%
68.0±20%
100.0±20%
Test Freq.
( Hz )
100K
100K
100K
100K
100K
100K
100K
100K
100K
100K
100K
100K
B：Taping Reel
RDC
(Ω )
max.
0.032
0.058
0.078
0.105
0.150
0.185
0.300
0.430
0.625
0.890
1.250
1.950
Irms
(A)
typ.
2.50
1.80
1.60
1.20
1.05
0.90
0.65
0.60
0.45
0.35
0.30
0.22
Isat
(A)
typ.
2.80
2.10
1.72
1.40
1.15
1.00
0.80
0.66
0.53
0.46
0.35
0.28
1).
□：Packaging
information … A：Bulk
2). "-
3).Inductance Test Freq : 100KHz / 1V
4). Irms Base on Temp. rise 40
℃
typ.
Isat Bae on
△
L/L0A=10 % typ.
□□□
":Reference code
@ Inductance VS. DC Superposition Characteristics
1000
100
Inductance ( uH )
101
330
10
100
3R3
1
0.1
0.01
0.1
1
10
DC Current ( A )
AR-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 3
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB5014□□□□L□-□□□
Ⅵ﹒PACKAGING
INFORMATION：
( 1 ) Configuration
T
2.0±0.5
A
N
Cover Tape
B
∮
C
∮
C
G
D
Embossed carrier
P:8 m/m
End
※
Carrier Tape width : D
4 m/m
Start
100
100
100
100
100
Leader
no component
200 m/m min.
Components
User direction of feed
Trailer
no component
400 m/m min.
( 2 ) Dimensions
Style
07-12
A
178
B
21±0.8
C
13
D
12
G
14
+0
N
50
-0
Unit:m/m
T
16.5
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SB5014
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
1000
120
07-12
40000
4.7
42 x 41 x 24
AR-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 4
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB5014□□□□L□-□□□
Ⅶ﹒DWGING
NUMBER EXPRESSION：
S
B
5
0
1
4
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Remark
Code
A
B
Inner package
T.B.D.
T / R ( Reel package )
Inner package Q'TY
T.B.D.
1000
pcs
AR-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 5
SMD POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SB5014□□□□L□-□□□
Ⅷ﹒RELIABILITY
TEST：
Test item
Specification
More than 90% of the
terminal electrode
Shall be covered
With fresh solder.
Test condition
Preheat : 150±25
℃
for 60 seconds
Solder : Sn96.5 / Ag3 / Cu0.5 or equivalent
Solder temp. : 235±5℃
Flux : Rosin
Dip time : 4±1 seconds
Solderability
Thermal shock test
( Temp. cycle )
Inductance shall
not change more
than ±20%
Room temp.
15 minutes
Room temp.
15 minutes
Total : 50 cycles
-25±2
℃
30 minutes
85±2
℃
30 minutes
Humidity
Resistance test
Temperature : 40±2℃
Humidity : 90 ~ 95%
Applied current : Per spec.
Time : 500 hours
High temp.
Resistance test
Temperature : 85±2℃
Applied current : Per spec.
Time : 500 hours
AR-001A
