SPECIFICATION FOR APPROVAL
REF :
20070101-A
PROD.
NAME
PAGE: 1
ABC'S DWG NO.
ABC'S ITEM NO.
SH2013□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A
A
F
I
B
C
: 2.60 ±0.20
: 2.60 ±0.20
: 1.35 ±0.15
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
A
D : 0.80 typ
E : 0.90 typ
F
G
H
I
J
R
: 2.90 ref
: 0.70 ref
: 1.70 ref
: 1.00 ref
: 0.90 ref
: 0.90 ref
B
R
or
F
C
E
D
D
( PCB Pattern Suggestion )
Ⅱ﹒SCHEMATIC
DIAGRAM：
G
H
G
I
J
LCR Meter
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Core：Ferrite RI core
c﹒Wire
：Enamelled
copper wire ( Class H )
d﹒Adhesive
：Epoxy
resin
e﹒Terminal：Ag/Ni/Sn
f﹒Remark：Products comply with RoHS'
requirements
250
Temperature (
℃
)
a
b
c
d
Peak Temp：260℃ max.
Max time above 230℃
：50sec
max.
Max time above 200℃
：70sec
max.
Temperature
Rising Area
+4.0
℃
/ sec max.
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
Reflow Area
e
Forced Cooling Area
+2.0 ~ 4.0
℃
-(1.0 ~ 5.0)
℃
/ sec max.
/ sec max.
Peak Temperature:
260℃
50sec max.
230℃
Ⅳ﹒GENERAL
SPECIFICATION：
a﹒Temp. rise
：40℃
max.
b﹒Storage temp.：-40℃ ----+125℃
c﹒Operating temp.：-40℃----+105℃
d﹒Resistance to solder heat：260℃.10 secs.
200
150
70sec max.
100
50
0
50
100
150
Time ( seconds )
200
250
AR-001A
SPECIFICATION FOR APPROVAL
REF :
20070101-A
PROD.
NAME
PAGE: 2
ABC'S DWG NO.
ABC'S ITEM NO.
SH2013□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅴ﹒
ELECTRICAL CHARACTERISTICS：
DWG No.
SH20131R0YL□ -□□□
SH20132R2YL□ -□□□
SH20133R3YL□ -□□□
SH20134R7YL□ -□□□
SH20136R8YL□ -□□□
SH2013100YL□ -□□□
SH2013150YL□ -□□□
SH2013220YL□ -□□□
SH2013330YL□ -□□□
SH2013470YL□ -□□□
1).
2)."-
Inductance
( µH )
1.0 ± 30
％
2.2 ± 30
％
3.3 ± 30
％
4.7 ± 30
％
6.8 ± 30
％
10.0 ± 30
％
15.0 ± 30
％
22.0 ± 30
％
33.0 ± 30
％
47.0 ± 30
％
RDC
Q Test Freq. SRF
( MHz )
( mΩ )
ref. ( MHz )
typ.
typ. max.
7
7
7
7
7
10
10
12
12
12
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
230
120
95
90
75
60
50
35
30
25
45
60
75 100
115 150
170 220
245 320
340 445
500 650
800 1040
1100 1450
1500 1950
Irms
( mA )
max.
2100
1600
1250
1100
1000
650
550
370
350
250
Isat
( mA ) Marking
typ.
1080
590
520
425
365
300
250
205
150
135
A
C
E
F
G
H
I
J
K
L
□□□
":Reference code
：Packaging
Information… A：Bulk
B：Taping Reel
3). Inductance Test Freq.
：100KHz
/0.1V
4). Irms base on Temp. rise 40
℃
max.
5). Isat base on
△
L / LOA=35% typ.
@ Inductance VS. DC Current Curve
1000
100
Inductance ( uH )
470
100
10
1
1R0
0.1
0.01
0.1
1
10
DC Current ( A )
AR-001A
SPECIFICATION FOR APPROVAL
REF :
20070101-A
PROD.
NAME
PAGE: 3
ABC'S DWG NO.
ABC'S ITEM NO.
SH2013□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅵ﹒PACKAGING
INFORMATION：
( 1 ) Configuration
T
Cover Tape
2.0±0.5
A
N
∮
C
∮
C
B
G
D
Embossed carrier
※
Carrier tape width : D
P:8 m/m
End
A
A
A
A
A
4 m/m
Start
A
A
A
Leader
no component
200 m/m min.
Components
User direction of feed
Trailer
no component
400 m/m min.
( 2 ) Dimensions
Style
07 - 12
A
178
B
21±0.8
C
13
D
12
G
14
+0
N
50
-0
Unit:m/m
T
16.5
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SH2013
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
1,500
120
07 - 12
60,000
4.8
42 x 41 x 24
AR-001A
SPECIFICATION FOR APPROVAL
REF :
20070101-A
PROD.
NAME
PAGE: 4
ABC'S DWG NO.
ABC'S ITEM NO.
SH2013□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅶ﹒DWGING
NUMBER EXPRESSION：
S
H
2
0
1
3
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
Inner package
T.B.D.
T / R ( Reel package )
Inner package Q'TY
T.B.D.
1,500
pcs
Remark
AR-001A
SPECIFICATION FOR APPROVAL
REF :
20070101-A
PROD.
NAME
PAGE: 5
ABC'S DWG NO.
ABC'S ITEM NO.
SH2013□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅷ﹒RELIABILITY
TEST：
Test item
Specification
More than 90% of the
terminal electrode
Shall be covered
With fresh solder.
Test condition
Preheat : 150±25
℃
for 60 seconds
Solder : Sn96.5 / Ag3 / Cu0.5 or equivalent
Solder temp. : 235±5℃
Flux : Rosin
Dip time : 4±1 seconds
Solderability
Thermal shock test
( Temp. cycle )
Inductance shall
not change more
than ±20%
Room temp.
15 minutes
Room temp.
15 minutes
Total : 50 cycles
-25±2
℃
30 minutes
85±2
℃
30 minutes
Humidity
Resistance test
Temperature : 40±2℃
Humidity : 90 ~ 95%
Applied current : Per spec.
Time : 500 hours
High temp.
Resistance test
Temperature : 105±2℃
Applied current : Per spec.
Time : 500 hours
AR-001A
