AMPMODU Interconnection System
Headers, Straight Post, Double-Row, .100 x .100 [2.54 x 2.54] Centerline
Solder Posts and
ACTION PIN Posts
(with Pin Protection
and Guide Pins)
Pos.
Ref.
1 2 3
.100
[2.54]
.065
R
[1.66]
(2 Plc.)
.515
[13.08]
.085
[2.16]
.040
[1.02]
(4 Sides)
.200
[5.08]
B
A
.130
[3.30]
(2 Plc.)
Material and Finish
Housing
— Glass-filled thermoplastic,
black, 94V-0 rated
Posts
— Phosphor bronze, plated as
follows:
Plating A
— Duplex plated .000030
[0.00076] gold on contact area,
.000100-.000200 [0.00254-0.00508]
matte tin on termination end, with entire
post underplated .000050 [0.00127]
nickel
Plating B
— Duplex plated .000015
[0.00038] gold on contact area,
.000100-.000200 [0.00254-0.00508]
matte tin on termination end, with entire
post underplated .000050 [0.00127]
nickel
Plating C
— Selectively plated .000030
[0.00076] gold on contact area and
.000015 [0.00038] gold on termination
end, with gold flash over .000050
[0.00127] nickel on entire post
.110
[2.79]
.200
[5.08]
(Localized
Gold Plate
Area)
.320
[8.13]
.440
[11.18]
.130
[3.30]
Board Retention Tails
(where indicated)
.180
[4.57]
.090
[2.29]
Printed Circuit Board
Connectors
.100±.003
[2.54±0.08]
.040±.003
[1.02±0.08]
(Finished Hole)
.180
[4.57]
.100±.003
[2.54±0.08]
.0453±.001
[1.02±0.03]
(Drilled Hole)
Recommended PC Board Hole Layout
(for .055 [1.40] min. thick PC board)
.025 [0.64] Square
Board Retention Tails
Tolerances not to accumulate within one connector pattern.
5
Related Product Data
Mateable Receptacles
—
pages 195, 196
Performance Specifications
—
page 194
ACTION PIN Posts
—pages 150, 151
Application Tooling
—pages 152
Dimensions
A
.980
[24.89]
1.080
[27.43]
1.180
[29.97]
1.380
[35.05]
1.580
[40.13]
1.880
[47.75]
2.180
[55.37]
2.380
[60.45]
2.880
[73.15]
3.380
[85.85]
3.880
[98.55]
3.980
[101.09]
4.380
[111.25]
4.680
[118.87]
4.880
[123.95]
5.180
[131.57]
5.380
[136.65]
5.880
[149.35]
6.380
[162.05]
6.880
[174.75]
10.380
[263.65]
B
.500
[12.70]
.600
[15.24]
.700
[17.78]
.900
[22.86]
1.100
[27.94]
1.400
[35.56]
1.700
[43.18]
1.900
[48.26]
2.400
[60.96]
2.900
[73.66]
3.400
[86.36]
3.500
[88.90]
3.900
[99.06]
4.200
[106.68]
4.400
[111.76]
4.700
[119.38]
4.900
[124.46]
5.400
[137.16]
5.900
[149.86]
6.400
[162.56]
9.900
[251.46]
Header Part Nos. with .180 [4.57] Tail Length
Standard Solder Tails
Board Retention Tails
Plating A
Plating B
Plating A
Plating B
5-102692-1 5-102567-1
6-534978-6
5-534257-5
—
7-102567-3
—
—
6-102692-5
—
5-534978-2
6-534257-4
6-102692-6
6-102567-1
5-534978-3
5-534257-6
5-102692-2
5-102567-2
5-534978-4
5-534257-7
6-102692-7
6-102567-3
5-534978-5
5-534257-8
5-102692-3
5-102567-3
5-534978-6
5-534257-9
6-102692-3
6-102567-2
5-534978-7
6-534257-0
5-102692-4
5-102567-6
5-534978-8
6-534257-5
5-102692-5
5-102567-4
5-534978-9
6-534257-1
6-102692-4
6-102567-0
6-534978-5
6-534257-2
6-102692-8
6-102567-6
6-534978-0
—
5-102692-6
5-102567-8
6-534978-1
5-534257-1
6-102692-9
6-102567-7
—
—
6-102692-2
6-102567-4
—
—
5-102692-7
5-102567-5
6-534978-7
—
5-102692-8
5-102567-9
6-534978-8
5-534257-2
6-102692-0
6-102567-5
6-534978-2
—
5-102692-9
5-102567-7
6-534978-3
5-534257-3
7-102692-0
6-102567-9
6-534978-9
—
6-102692-1
7-102567-1
5-534978-1
6-534257-9
No. of
Pos.
12
14
16
20
24
30
36
40
50
60
70
72
80
86
90
96
100
110
120
130
200
Technical Documents
— page 276
Product Specification
108-25017
Application Specification
114-9009
Additional header sizes are
available; minimum order
quantities may apply. Consult
Tyco Electronics.
Note:
Headers with make first/break last posts can be made available, consult Tyco Electronics.
Note:
All part numbers are RoHS compliant.
198
Catalog 1307819
Revised 8-08
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-470-4425
Mexico: 01-800-733-8926
C. America: 52-55-1106-0803
South America: 55-11-2103-6000
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-8706-080-208
AMPMODU Interconnection System
Headers, Straight Post, Double-Row, .100 x .100 [2.54 x 2.54]
Centerline
(Continued)
See chart
below
.025 [0.64] Square
ACTION PIN Tails
No. of
Pos.
12
14
20
24
36
40
50
60
70
80
90
96
100
120
130
Dimensions
A
.980
[24.89]
1.080
[27.43]
1.380
[35.05]
1.580
[40.13]
2.180
[55.37]
2.380
[60.45]
2.880
[73.15]
3.380
[85.85]
3.880
[98.55]
4.380
[111.25]
4.880
[123.95]
5.180[131.57]
5.380
[136.65]
6.380
[162.05]
6.880
[174.75]
B
.500
[12.70]
.600
[15.24]
.900
[22.86]
1.100
[27.94]
1.700
[43.18]
1.900
[48.26]
2.400
[60.96]
2.900
[73.66]
3.400
[86.36]
3.900
[99.06]
4.400
[111.76]
4.700
[119.38]
4.900
[124.46]
5.900
[149.86]
6.400
[162.56]
Header Part Nos. with ACTION PIN Posts
.250 [6.35] Tail Length .480 [12.19] Tail Length
.680 [17.27] Tail Length
Plating A
Plating B
Plating A
Plating C
Plating C
5-102690-1 5-103291-4
—
—
—
—
5-103291-3
—
—
—
6-102690-3 5-103291-6
—
—
—
5-102690-2 5-103291-7
—
—
—
5-102690-3 5-103291-9
—
—
—
6-102690-6 5-103291-2
—
—
—
5-102690-4 6-103291-0
—
—
—
5-102690-5 6-103291-1
—
—
—
6-102690-7 6-103291-2
—
—
—
5-102690-6 6-103291-4
—
—
—
6-102690-1 6-103291-6
—
—
—
5-102690-7 6-103291-8
—
—
—
5-102690-8 6-103291-9
—
—
102777-3
5-102690-9 7-103291-1 5-102691-9 1-102666-1
102777-1
—
—
—
102666-9
—
Printed Circuit Board
Connectors
Notes:
1. Other header sizes can be made available upon request.
Headers with ACTION PIN posts are for use with .093 [2.36] nominal or thicker PC boards.
2. Application tooling for installing headers with ACTION PIN posts is shown on pages 152 and 153.
3. Headers with .250 [6.35] tail length can be made available with make first/break last contacts,
consult Tyco Electronics.
4. Plated through holes to be prepared per recommendations found on page 151.
5
Note:
All part numbers are RoHS compliant.
199
Catalog 1307819
Revised 8-08
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-470-4425
Mexico: 01-800-733-8926
C. America: 52-55-1106-0803
South America: 55-11-2103-6000
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-8706-080-208
