DIP Type
SBPSC Coils
11R310½12R817 Series
〈Magnetically
Shielded Type〉
〈Magnetically
Shielded Type〉
［RoHS
Compliant½
［RoHS
Compliant½
●SBPSC-11R310 Series
Model
11R310-100A
11R310-120A
11R310-150A
11R310-220A
11R310-270A
11R310-330A
11R310-390A
11R310-470A
11R310-560A
11R310-680A
11R310-820A
11R310-101A
11R310-121A
11R310-151A
11R310-221A
11R310-271A
11R310-331A
11R310-391A
11R310-471A
11R310-681A
11R310-821A
11R310-102A
Inductance
DC resistance
（μH）
（Ω）
max.
（100KHz.1mA）
±20%
10
36m
±20%
12
48m
±20%
15
51m
±20%
22
87m
±20%
27
106m
±20%
33
132m
±20%
39
141m
±20%
47
181m
±20%
56
200m
±20%
68
221m
±20%
82
251m
±15%
100
272m
±15%
120
299m
±15%
150
390m
±15%
220
736m
±15%
270
839m
±15%
330
936m
±15%
390
1.20
±15%
470
1.40
±15%
680
2.00
±15%
820
2.30
±15%
1000
2.60
Reted
Current
（A）
3.80
3.40
3.30
2.85
2.40
2.10
2.05
1.80
1.75
1.65
1.55
1.45
1.40
1.15
0.94
0.88
0.84
0.74
0.70
0.48
0.46
0.43
●SBPSC-12R817 Series
Model
12R817-100A
12R817-120A
12R817-150A
12R817-220A
12R817-270A
12R817-330A
12R817-390A
12R817-470A
12R817-560A
12R817-680A
12R817-820A
12R817-101A
12R817-121A
12R817-151A
12R817-221A
12R817-271A
12R817-331A
12R817-391A
12R817-471A
12R817-561A
12R817-681A
12R817-821A
12R817-102A
Package: Bulk・800pcs/box
Package: Bulk・1,600pcs/box
Inductance
DC resistance
（μH）
（Ω）
max.
（100KHz.1mA）
±20%
29m
10
±20%
32m
12
±20%
35m
15
±20%
43m
22
±20%
48m
27
±20%
52m
33
±20%
58m
39
±20%
61m
47
±20%
66m
56
±20%
75m
68
±20%
96m
82
±15%
0.14
100
±15%
0.18
120
±15%
0.26
150
±15%
0.40
220
±15%
0.47
270
±15%
0.53
330
±15%
0.57
390
±15%
0.62
470
±15%
0.70
560
0.84
680
±15%
0.94
820
±15%
1.10
1000
±15%
Reted
Current
（A）
4.70
4.40
4.20
3.90
3.60
3.50
3.30
3.20
3.10
2.90
2.50
2.40
2.20
1.65
1.40
1.30
1.20
1.15
1.10
1.00
0.90
0.80
0.70
*The rated current is the lower value of the following two: the DC curent value when the inductance decreases 10% from the initial value , or the DC current
value when the coil's temperature has rose
ΔT=40˚C
●Operating
temperature range: –20 to +105˚C (Incl. coil heat)
Shape and Dimensions
●SBPSC-11R310 Series
●SBPSC-12R817 Series
wind end mark
（ø1.0
notch on the core）
wind end mark
（ø1.0
notch on the core）
12.0 max.
13.5 max.
10.5 max.
5.0±1.0
ø0.6
ø0.65
5.0±1.0
17.0 max.
5.0±0.5
5.0±0.5
[mm]
Choke Coils VOL.04
●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC Tokin for updated product data.
●Please request for a specification sheet for detailed product data prior to the purchase.
●Before using the product in this catalog, please read "Precautions" and other safety precautions listed in the printed version catalog.
2006.03.22 P0718MCCC10VOL04E
