LANCW8 Series
Single and Dual Output
8 Watt DC/DC Converter
2:1 Wide Input Voltage Range
FEATURES
APPLICATIONS
●
Measurement
●
8 Watts Output Power
●
Wireless Network
●
Output Current up to 2A
●
Telecom/Datacom
●
High Efficiency up to 85%
●
Industry Control System
●
Five-Sided Continuous Shield
●
Semiconductor Equipment
●
2:1 Wide Input Voltage Range
●
Fixed Switching Frequency (300KHz)
●
Standard 1.25 x 0.8 x 0.4 Inch Package
●
ISO9001 Certified Manufacturing Facilities
●
Compliant to RoHS EU Directive 2002/95/EC
●
Standard 24 Pin DIP Package & SMT Type Package
SPECIFICATIONS:
LANCW8 Series
All specifications apply @ 25°C ambient unless otherwise noted
INPUT SPECIFICATIONS
Input Voltage Range ............ 12V nominal input .......................... 9-18VDC
24V nominal input ........................ 18-36VDC
48V nominal input ........................ 36-75VDC
Input Filter ....................................................................................... Pi Type
Input Surge Voltage (100ms max) ....... 12V input ...........................36VDC
24V input ...........................50VDC
48V input .........................100VDC
Input Reflected Ripple Current (nominal Vin and full load) ...........20mAp-p
Start Up Time (nominal Vin and constant resistive load) .........700ms max.
Remote ON/OFF (See Note 6)
(Positive Logic)............... DC-DC ON .............Open or 3.5V < Vr < 12V
DC-DC OFF .............Short or 0V < Vr < 1.2V
Input Current of Remote Control Pin (nominal Vin) ........ -0.5mA ~ +0.5mA
Remote Off State Input Current (nominal Vin) ..................................2.5mA
GENERAL SPECIFICATIONS (Continued)
Isolation Voltage
Input to Output ............................................................... 1600VDC min.
Input (Output) to Case (DIP).......................................... 1600VDC min.
Input (Output) to Case (SMT) ........................................ 1000VDC min.
Isolation Resistance ...............................................................10 ohms min.
Isolation Capacitance ............................................................... 300pF max.
9
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature ................................ -40°C ~ +85°C (with derating)
Storage Temperature .......................................................... -55°C ~ +105°C
Maximum Case Temperature ............................................................. 100°C
Relative Humidity (non-condensing) .....................................5% to 95% RH
Thermal Impedance (Natural Convection) ................................. 20°C / Watt
Thermal Shock ..................................................................... MIL-STD-810F
Vibration ................................10~55Hz, 10G, 30 minutes along X, Y, and Z
MTBF (See Note 1) .......................................................... 3.053 x 10 hours
6
OUTPUT SPECIFICATIONS
Output Voltage ..............................................................................see table
Voltage Accuracy (nominal Vin and full load) ...................................... ±1%
Output Current ..............................................................................see table
Output Power .......................................................................... 8 watts max.
Line Regulation (LL to HL at FL)....................................................... ±0.2%
Load Regulation (no load to full load) ...... Single Output (DIP) ....... ±0.5%
Single Output (SMT).......... ±1%
Dual Output (SMT, DIP) .... ±1%
Cross Regulation (Dual) (Asymmetrical load 25% / 100% FL) ............ ±5%
Minimum Load ....................................................................................... 0%
Ripple/Noise (20 MHz BW) ...........................................................50mVp-p
Temperature Coefficient ................................................. ±0.02% / °C max.
Transient Response Recovery Time (25% load step) .......................200us
PHYSICAL SPECIFICATIONS
Weight ....................................DIP Type ................................. 16g (0.55 oz)
SMT Type................................ 18g (0.62 oz)
Dimensions................... 1.25 x 0.80 x 0.40 inches (31.8 x 20.3 x 10.2 mm)
Case Material ..............................................................Nickel-coated copper
Base Material...................................................Non-conductive black plastic
Potting material..................................................................Epoxy (UL94-V0)
Shielding...................................................................................... five - sided
SAFETY & EMC
Approvals and Standards .................. IEC60950-1, UL60950-1, EN60950-1
EMI (Note 7) .......................EN55022 .............................................. Class A
ESD ....................EN61000-4-2……..
Air ± 8KV …….Perf. Criteria B
Contact ± 6KV
PROTECTION SPECIFICATIONS
Over Load Protection (% of full load at nominal input).............. 150% max.
Short Circuit Protection. ............................Continuous, automatic recovery
Radiated Immunity..............EN61000-4-3............... 10V/m Perf. Criteria A
Fast Transient.....................EN61000-4-4................. ±2KV Perf. Criteria B
Surge (See Note 8).............EN61000-4-5................. ±1KV Perf. Criteria B
Conducted Immunity...........EN61000-4-6............ 10 Vrms Perf. Criteria A
GENERAL SPECIFICATIONS
Efficiency.......................................................................................see table
Switching Frequency................................................................300KHz typ.
Due to advances in technology, specifications subject to change without notice
Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833
603-778-2300 www.wallindustries.com Fax 603-778-9797
LANCW8 Series
Single and Dual Output
8 Watt DC/DC Converter
2:1 Wide Input Voltage Range
OUTPUT VOLTAGE / CURRENT RATING CHART
Model Number
LANC123.3W8
LANC1205W8
LANC1212W8
LANC1215W8
LANC1205DW8
LANC1212DW8
LANC1215DW8
LANC243.3W8
LANC2405W8
LANC2412W8
LANC2415W8
LANC2405DW8
LANC2412DW8
LANC2415DW8
LANC483.3W8
LANC4805W8
LANC4812W8
LANC4815W8
LANC4805DW8
LANC4812DW8
LANC4815DW8
Input Range
Output
Voltage
3.3 VDC
5 VDC
12 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
Output Current
Min. load Full load
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
2000mA
1500mA
666mA
533mA
±800mA
±333mA
±267mA
2000mA
1500mA
666mA
533mA
±800mA
±333mA
±267mA
2000mA
1500mA
666mA
533mA
±800mA
±333mA
±267mA
Output
(4)
Ripple & Noise
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
(5)
Input Current
(4)
Capacitor
Efficiency
Load max
No load
(3)
Full load
(2)
12 VDC
(9 – 18 VDC)
24 VDC
(18 – 36 VDC)
48 VDC
(36 – 75 VDC)
10mA
15mA
13mA
20mA
15mA
20mA
20mA
10mA
30mA
13mA
15mA
15mA
15mA
13mA
7mA
8mA
10mA
10mA
8mA
8mA
7mA
724mA
791mA
792mA
802mA
843mA
802mA
824mA
362mA
396mA
406mA
411mA
427mA
406mA
411mA
181mA
198mA
203mA
203mA
205mA
200mA
201mA
80%
83%
88%
87%
83%
87%
85%
80%
83%
86%
85%
82%
86%
85%
80%
83%
86%
86%
85%
87%
87%
3300uF
1600uF
350uF
240uF
±1000uF
±160uF
±100uF
3300uF
1600uF
350uF
240uF
±1000uF
±160uF
±100uF
3300uF
1600uF
350uF
240uF
±1000uF
±160uF
±100uF
NOTES
1.
2.
3.
4.
5.
6.
7.
BELLCORE TR-NWT-000332. Case I: 50% Stress, Temperature at 40ºC. (Ground fixed and controlled environment).
Maximum value at nominal input voltage and full load of standard type.
Typical value at nominal input voltage and no load.
Typical value at nominal input voltage and full load.
Test by minimum Vin and constant resistive load.
The ON/OFF control pin voltage is referenced to –Vin.
The LANCW8 Series can meet EN55022 Class A with an external capacitor in parallel with the input pins.
Recommended: 12Vin: 4.7µF/25V
24Vin: N/A.
48Vin: N/A.
An external filter capacitor is required if the module has to meet EN61000-4-5. The filter capacitor Wall Industries suggests: Nippon chemi-con
KY Series, 220µF/100V, ESR 48mΩ.
8.
DERATING CURVE & EFFICIENCY GRAPHS
FKC08-48S05 Derating Curve
LANC4805W8 Derating
120
120
Curve
Output Power (%)
OUTPUT POWER(%)
100
100
80
80
60
40
20
0
0
-40
-40
-20
-20
0
20
20
40
40
60
69.2
80
60
69.2
80
100
100
120
120
90
90
FKC08-48S05
Efficiency VS Input Voltage
LANC4805W8 Efficiency vs Input
Ambient Temperature (°C)
AMBIENT TEMPERATURE,TA(
(°C)
Ambient Temperature, TA
℃
)
90
90
FKC08-48S05
Efficiency VS Output
Efficiency vs Output Load
LANC4805W8
Load
EFFICENCY(% )
EFFICENCY(%)
Efficiency (%)
Efficiency (%)
85
85
80
80
75
75
70
70
65
65
85
85
80
80
75
75
70
70
65
65
60
60
10
10
60
60
36
36
40
40
44
44
48
48
52
52
56
56
60
60
64
64
68
68
72
72
75
75
20
20
30
40
40
50
50
60
60
70
70
80
80
90
100
100
Vin(V)
Vin (V)
% of FULL LOAD
% of Full Load
