Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Plug connectors,
THR solder connection, pitch 3.5 | SL-SMT 3.5/90LF | SL-SMT 3.5/90LF Tape
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Fitted to PCB
Outgoing elbow
Pitch
Pitch in inch
No. of poles
Solder pin length
Can be coded
No. of rows
1805340000
SL-SMT3.5/5/90LF 1.5SN
PCB plug-in connector, Male connectors, Reflow
solder connection, Pitch: 3.50 mm, No. of poles: 5,
90°, Tape
4032248269594
385 pc(s).
Reflow solder connection
90°
3.5 mm
0.138 inch
5
1.5 mm
Yes
1
-1-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Plug connectors,
THR solder connection, pitch 3.5 | SL-SMT 3.5/90LF | SL-SMT 3.5/90LF Tape
System parameters
No. of solder pins per pole
Dia. of fitting hole
Fitting hole tolerance
L1 in mm
L1 in inch
Insulation resistance
Electric shock protection to DIN VDE 0470
Electric shock protection to DIN VDE 0470
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Temperature of glow-wire test
Duration of glow-wire test
Contact base material
Contact surface
Constant operating temp., min.
Constant operating temp., max.
Storage temperature, min.
Storage temperature, max.
Max. relative humidity during storage
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, max. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated current, max. No. pins (Tu=40°C)
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Rated voltage for overvoltage class/pollution
severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated voltage for overvoltage class/pollution
severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
UL 1059 rating data
Rated voltage (Use group D)
1
1.4 mm
+ 0.1 mm
14 mm
0.551 inch
1 MΩ
IP 10
Safe from back-of-hand touch
LCP GF
black
Similar to RAL 9011
IIIa
V-0
>= 175
960 °C
30 S
CuSn
tinned
-25 °C
100 °C
-25 °C
55 °C
80 %
15 A
12 A
13 A
10 A
160 V
2.5 kV
160 V
2.5 kV
320 V
2.5 kV
3 x 1s with 100 A
300 V
10 A
300 V
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Plug connectors,
THR solder connection, pitch 3.5 | SL-SMT 3.5/90LF | SL-SMT 3.5/90LF Tape
UL 1059 rating data
Rated current (Use group D)
Approvals
Approvals institutes
10 A
Downloads
CAD Library (P-CAD Format - Standard)
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
SL-SMT.LIB
NK
EC001284
27-26-07-01
27-26-07-01
27-26-07-04
Similar products
Order No.
1805310000
1805320000
1805330000
1805350000
1805360000
1805370000
1805380000
1005180000
Part designation
SL-SMT3.5/2/90LF 1.5SN
SL-SMT3.5/3/90LF 1.5SN
SL-SMT3.5/4/90LF 1.5SN
SL-SMT3.5/6/90LF 1.5SN
SL-SMT3.5/7/90LF 1.5SN
SL-SMT3.5/8/90LF 1.5SN
SL-SMT3.5/9/90LF 1.5SN
SL-SMT3.5/10/90LF 1.5SR SW
Version
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 2, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 3, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 4, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 6, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 7, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 8, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 9, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 10, 90°, Tape
-3-
