2-175707-2 Product Details
Live Product Chat
Product View
.050 Series Cable Connectors (SCSI)
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
2-175707-2
T E I nternal N umber: 2 - 1 7 5 7 0 7 - 2
Product Highlights:
l
C onnector
l
Plug
l
Number of Positions = 28
l
Wire/C able Type = Discrete Wire
l
Wire Range = 0.05² [30] mm [AWG]
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
REPRESENTATIVE TERMINALS AND C ONNEC TORS
(PDF, English)
Product Specifications:
l
No title
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Plug
l
Number of Positions = 28
l
Wire/C able Type
= Discrete Wire
l
Wire Insulation Diameter (mm [in])
= 0.79 – 0.88 [0.031 – 0.035]
l
Mating C onnector Lock
= Without
l
Shielded
= Yes
l
Detent
= With
l
Rails
= Without
l
Termination C over
= With
l
Product Series
= Series II
l
Wire Termination Type = IDC
l
C olor = Gray
l
Shell Material = Steel
Mechanical Attachment:
l
Panel Attachment
= Without
Termination Related Features:
l
Solder Tail C ontact Plating = Nickel
Body Related Features:
l
Wire Range (mm [AWG]) = 0.05² [30]
l
Shell Plating = Tin over C opper
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
l
C ontact Mating Area Plating Material = Gold (8)
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Conditions for Usage:
l
Terminate To = Wire
Other:
l
Brand = AMP
