P-CHANNEL
POWER MOSFET
2N6851
•
•
•
•
Hermetic TO39 Metal Package
Dynamic dv/dt Rating
Simple Drive Requirements
Screening Options Available
ABSOLUTE MAXIMUM RATINGS
(Tcase = 25°C unless otherwise stated)
VDS
VGS
ID
ID
IDM
(1)
PD
dv/dt
(2)
TJ
Tstg
Drain – Source Voltage
Gate – Source Voltage
Continuous Drain Current @ Tcase = 25°C
Continuous Drain Current @ Tcase = 100°C
Pulsed Drain Current
Total Power Dissipation @ Tcase = 25°C
Linear De-rating Factor @ Tcase
≥
25°C
Peak Diode Recovery dv/dt
Operating Temperature Range
Storage Temperature Range
-200V
±20V
-4.0A
-2.4A
-16A
25W
200mW/°C
-5V/ns
-55°C to +150°C
-55°C to +150°C
THERMAL CHARACTERISTICS
Symbol
R
θJC
Notes:
1)
2)
3)
4)
Repetitive Rating; Pulse width limited by maximum junction temperature
ISD
≤
-4.0A, di/dt
≤
-120A/µs, VDD
≤
-200V, TJ
≤
150°C
Pulse width
≤
380 µs; Duty Cycle
≤
2%
By design. Not a production test.
Parameters
Thermal Resistance, Junction To Case
Max
5
Units
°C/W
Semelab Limited reserves the right to change test conditions, parameter limits and package dimensions without notice.
Information furnished by Semelab is believed to be both accurate and reliable at the time of going to press. However
Semelab assumes no responsibility for any errors or omissions discovered in its use. Semelab encourages customers to
verify that datasheets are current before placing orders.
Semelab Limited
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Telephone +44 (0) 1455 556565
Fax +44 (0) 1455 552612
Email:
sales@semelab-tt.com
Document Number 10351
Issue 1
Page 1 of 3
Website:
http://www.semelab-tt.com
P-CHANNEL
POWER MOSFET
2N6851
ELECTRICAL CHARACTERISTICS
(Tcase = 25°C unless otherwise stated)
Symbol
BVDSS
Parameters
Drain-Source Breakdown
Voltage
Temperature Coefficent of
Breakdown Voltage
Static Drain-Source
On-State Resistance
Test Conditions
VGS = 0
Reference
to 25°C
VGS = -10V
VGS = -10V
VDS
≥
VGS
ID = -1.0mA
ID = -1.0mA
ID = -2.4A
ID = -4.0A
Tj = 125°C
ID = -250µA
Tj = 125°C
Tj = -55°C
VDS
≥
-15V
VGS = 0
IDS = -2.4A
VDS = 0.8BVDSS
Tj = 125°C
VGS = ±20V
Tj = 125°C
Min
-200
Typ
Max
Units
V
∆
BVDSS
∆
Tj
RDS(on)
(3)
-0.22
0.80
0.83
1.60
-2.0
-1.0
-5.0
2.2
-25
-250
±100
±200
-4.0
V/°C
Ω
VGS(th)
gfs
(3)
Gate Threshold Voltage
Forward Transconductance
Zero Gate Voltage
Drain Current
Gate-Source Leakage
V
S(Ʊ)
µA
IDSS
IGSS
IGSS
nA
DYNAMIC CHARACTERISTICS
Ciss
Coss
Crss
Qg
(4)
(4)
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Total Gate Charge
Gate-Source Charge
Gate-Drain Charge
Turn-On Delay Time
Rise Time
Turn-Off Delay Time
Fall Time
VGS = 0
VDS = -25V
f = 1.0MHz
VGS = -10V
ID = -4.0A
VDS = 0.5BVDSS
VDD = -100V
ID = -4.0A
RG = 7.5Ω
VGS = -10V
14.7
0.8
5.0
700
200
40
34.8
7.0
17
50
100
100
80
ns
nC
pF
Qgs
Qgd
(4)
td(on)
tr
td(off)
tf
SOURCE – DRAIN DIODE CHARACTERISTICS
IS
ISM
VSD
trr
(3)
(3)
Continuous Source Current
Pulse Source Current
Diode Forward Voltage
Reverse Recovery Time
Reverse Recovery Charge
Forward Turn - on Time
IS = -4.0A
IF = -4.0A
di/dt
≤
-100A/µs
Negligible
VGS = 0
VDD
≤
-50V
-4.0
-16
-6.0
400
4.0
A
V
ns
µC
Qrr
(3)(4)
ton
PACKAGE CHARACTERISTICS
LD
LS
Internal Drain Inductance
Internal Source Inductance
5.0
15
nH
Semelab Limited
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Telephone +44 (0) 1455 556565
Fax +44 (0) 1455 552612
Email:
sales@semelab-tt.com
Website:
http://www.semelab-tt.com
Document Number 10351
Issue 1
Page 2 of 3
P-CHANNEL
POWER MOSFET
2N6851
MECHANICAL DATA
Dimensions in mm (inches)
8.51 (0.34)
9.40 (0.37)
7.75 (0.305)
8.51 (0.335)
6.10 (0.240)
6.60 (0.260)
12.70
(0.500)
min.
0.89
max.
(0.035)
0.41 (0.016)
0.53 (0.021)
dia.
5.08 (0.200)
typ.
2
1
0.74 (0.029)
1.14 (0.045)
0.71 (0.028)
0.86 (0.034)
2.54
(0.100)
3
45°
TO-39 (TO-205AD) METAL PACKAGE
Underside View
Pin 1 - Source
Pin 2 - Gate
Pin 3 - Drain
