Part Number

Search

7-134577-1

Description
CONNECTOR, PANEL MOUNT, CABLE TERMINATED, FEMALE, BNC CONNECTOR, CRIMP, JACK, ROHS COMPLIANT
CategoryThe connector    The connector
File Size106KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

7-134577-1 Overview

CONNECTOR, PANEL MOUNT, CABLE TERMINATED, FEMALE, BNC CONNECTOR, CRIMP, JACK, ROHS COMPLIANT

7-134577-1 Parametric

Parameter NameAttribute value
Objectid2056285838
package instructionROHS COMPLIANT
Reach Compliance Codeunknown
Other featuresAPPLICABLE CABLES: RG 140/U, RG 59/U, RG 62/U, RG 71/U
Body/casing typeJACK
Characteristic impedance75 Ω
Connector typeRF BNC CONNECTOR
Contact to complete cooperationGOLD
Contact completed and terminatedGOLD
Contact point genderFEMALE
Coupling typeBAYONET
DIN complianceNO
Filter functionNO
IEC complianceNO
insulator materialPOLYTETRAFLUOROETHYLENE
JESD-609 codee4
MIL complianceNO
Installation methodSTRAIGHT
Installation typeCABLE AND PANEL
OptionsGENERAL PURPOSE
Panel mountingYES
Termination typeCRIMP
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
RF & C oax
>
Product Feature Selector
> Product Details
7-134577-1 Product Details
Live Product Chat
Product View
BNC RF Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
7-134577-1
T E I nternal N umber: 7 - 1 3 4 5 7 7 - 1
Product Highlights:
l
C onnector
l
C onnector Type = BNC
l
Jack
l
Terminate To C oaxial C able
l
C oaxial C able Termination Type = C rimp
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
PANEL JAC K
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type
= BNC
l
Gender
= Jack
l
C rimp Type
= Hex
l
Body Style
= Straight
l
Grade
= Professional
l
Body Material
= Brass
l
Sealed
= No
l
Isolated
= No
l
Dielectric Material
= PTFE
l
Mounting Hole Diameter (mm [in]) = 3.56 [.140]
l
Number of Ports = 1
l
Solder Terminal = Without
Mechanical Attachment:
l
Surface Mountable = No
l
Panel Attachment
= With
l
Panel Attachment Method
= Flange
l
Panel Attachment Style = Rear Mount, Front Mount
Electrical Characteristics:
l
C onnector Impedance (?)
= 75
Termination Related Features:
l
C oaxial C able Termination Type
= C rimp
Body Related Features:
l
Hardware Included
= No
l
Body Plating
= Nickel
l
Polarized
= No
l
Mount Direction = M2
l
Hexcrimp Dimension (mm [in]) = 6.48 [0.255]
Contact Related Features:
l
C enter C ontact Material
= Beryllium C opper
l
C enter C ontact Plating
= Gold
Configuration Related Features:
l
C oaxial C able Type (RG/U or Mfg.)
= 140, 59, 62, 71, KX 25, KX 30,
KX 52, KX 53, KX 6, URM 70, URM 90
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Terminate To
= C oaxial C able
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Additional Product Images:
l
Mounting Specifications
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved
