BTCPower
HB 48 Series
Description
TM
Broadband TelCom Power,
Inc.
Redefining “Current” Limits In Power Conversion
Up to 30A Low Cost Half Bricks
The HB series of low cost DC/DC converters offer the
different current levels and are comparable to existing
quarter-bricks. With a wide input voltage range of 36-75V
they are available with an output voltage of either 3.3, 5.0,
12, 15 or 24Volts. All models feature an input filter, output
overvoltage and overtemperature protection, output current
limiting and short circuit protection. The unique frame
construction with aluminum heat spreader design achieves
efficient heat transfer with no hot spots. The use of patented
Flat Matrix Transformer technology and other patent-pending
design concepts facilitate maximum power delivered. The
converters combine creative design concepts with highly
derated power devices to achieve very high reliability, high
performance and offer a low cost solution to systems
designers that are challenged to maximize power and
minimize board space.
Features
•
Delivers up to 30A in Half Brick
•
•
•
•
•
•
•
High efficiency patented topology
Low profile of only 0.50 inch
3.3V, 5.0V, 12V, 15V or 24V output modules
100V/100ms Input transient capability
-40°C to +85 °C ambient operation
Meets Basic Insulation requirements of EN60950
UL 1950 recognized, CAN / CSA C22.2 No. 950-95
Certified, and TUV EN60950 ( pending )
Specification Summary
• 10A-30A @ 3.3V, 10A-30A @ 2.5V,
4.16A-12.5A @ 12V, 3.33A-10A @ 15V
2.08A-6.25A @ 24V
• Tight output regulation, typical ±1%
• No minimum load required
• Ripple & Noise (20Mhz BW) 100 mV (pk-pk)
• Wide input operating range 36-75V
• On/Off pin and remote sense
• Output adjustment +/-10% range
• Meets conducted limits of FCC Class B and CEI
IEC61204-3 Class B with external filter
Applications
•
Telecommunications
•
•
•
•
•
•
Data Communications
Wireless Communications
Networking Gear
Servers, Switches and Data Storage
Semiconductor Test Equipment
Distributed Power Architecture
• 1500V, 10M
input-to-output isolation
• Frame construction with heat spreader for low
temperature rise
• Output overcurrent and overvoltage protection
• Over Temperature protection
• Input Under voltage protection
• MTBF of 1,600,000 hours @ 50°C ( Bellcore )
Broadband TelCom Power, Inc. –
1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A.
Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com
PB HB 48 Rev2 16-1-04
HB 48 Series
Up to 30A Low Cost Half Bricks
BTCPower
Output
TM
Product Brief
Part Number and Selection Information
Model
Part Number
Positive Logic
HB50-48-33
HB50-48-05
HB50-48-12
HB50-48-15
HB50-48-24
HB75-48-33
HB75-48-05
HB75-48-12
HB75-48-15
HB75-48-24
HB100-48-33
HB100-48-05
HB100-48-12
HB100-48-15
HB100-48-24
HB150-48-33
HB150-48-05
HB150-48-12
HB150-48-15
HB150-48-24
Negative Logic
HB50-48-33N
HB50-48-05N
HB50-48-12N
HB50-48-15N
HB50-48-24N
HB75-48-33N
HB75-48-05N
HB75-48-12N
HB75-48-15N
HB75-48-24N
HB100-48-33N
HB100-48-05N
HB100-48-12N
HB100-48-15N
HB100-48-24N
HB150-48-33N
HB150-48-05N
HB150-48-12N
HB150-48-15N
HB150-48-24N
Voltage (Volts)
Nominal
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
Range
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
36-75
Input
Current (A)
No load
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
Full load
0.87
1.25
1.22
1.22
1.24
1.24
1.88
1.84
1.84
1.72
1.72
2.48
2.45
2.46
2.61
2.61
3.77
3.68
3.67
3.67
Efficiency
75% Load
(%)
79
83
85
85
84
79
83
85
85
86
80
84
85
85
85
79
83
85
85
85
Voltage
(Volts)
3.3
5.0
12
15
24
3.3
5.0
12
15
24
3.3
5.0
12
15
24
3.3
5.0
12
15
24
Current
(Amps)
10
10
4.16
3.33
2.08
15
15
6.25
5.0
3.13
20
20
8.3
6.7
4.17
30
30
12.5
10
6.25
Typical at Ta= +25 ºC under nominal line voltage and 75% load conditions, unless noted.
Outline Information and Pin-out
Pin Connection
Pin#
Function
1
2
3
4
5
6
7
8
9
Vin +
On/Off
Case
Vin -
Vout -
Sense -
Trim
Sense +
Vout +
All dimensions are in inches [mm]
Pin 5 and 9 are dia. 0.08 [2.03]
All other pins are all dia. 0.040 [1.02]
Pin material: Brass
Pin finish: Tin/Lead plated
Heat spreader (baseplate) material:
Aluminum
Weight: 60.5g
The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are
subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines.
Broadband TelCom Power, Inc. –
1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A.
Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com
PB HB 48 Rev2 16-1-04
