AMPMODU Interconnection System
Headers, Right-Angle Post, Double-Row, .100 x .100 [2.54 x 2.54]
Centerline
Card Extender
(with Pin Protection
and Guide Pins)
.762
Max.
[19.35]
.599
[15.21]
Material and Finish
Housing
— Glass-filled thermoplastic,
black, 94V-0 rated
Posts
— Phosphor bronze, plated as
follows:
Plating A
— Duplex plated .000030
[0.00076] gold on contact area,
.000100-.000200 [0.00254-0.00508]
matte tin on termination end, with entire
post underplated .000050 [0.00127]
nickel
Plating B
— Duplex plated .000015
[0.00038] gold on contact area,
.000100-.000200 [0.00254-0.00508]
matte tin on termination end, with entire
post underplated .000050 [0.00127]
nickel
.040
[1.02]
Typ.
.100
[2.54]
A
.320
[8.13]
.320
[8.13]
.065
R
[1.65]
(2 Plc.)
.200
[5.08]
Typ.
2 3 4
Pos.
Ref.
B
.185
[4.70]
Typ.
Board Retention Tails
(where indicated)
.100
[2.54]
(Localized
Gold Plate
Area)
.125
[3.18]
.157
[3.99]
.100
[2.54]
Printed Circuit Board
Connectors
.040±.003
[1.02±0.08]
.100±.003
(Finished [2.54±0.08]
Hole
w/Bd. Ret.)
.157
[3.99]
.125
[3.18]
Related Product Data
Mateable Receptacles
—
pages 195, 196
Performance Specifications
—
page 194
.035±.003
Dia. Typ.
[0.89±0.08]
(Standard
Finished Hole)
.100±.003
[2.54±0.08]
.025 [0.64] Square
Board Retention Tails
5
Recommended PC Board Hole Layout
(for .055 [1.40] min. thick PC board)
Technical Documents
— page 276
Product Specification
108-25017
Application Specification
114-9009
Additional header sizes are
available; minimum order
quantities may apply. Consult
Tyco Electronics.
Tolerances not to accumulate within one
connector pattern.
Header Part Nos. with .125 [3.18] Tail Length
Standard Solder Tails
Board Retention Tails
A
B
Plating A
Plating B
Plating A
12
.980
[24.89]
.500
[12.70]
6-102802-2
5-102589-8
5-534245-5
16
1.180
[29.97]
.700
[17.78]
6-102802-4
—
5-534245-4
20
1.380
[35.05]
.900
[22.86]
6-102802-5
6-102589-2
5-534245-6
24
1.580
[40.13]
1.100
[27.94]
6-102802-3
5-102589-6
5-534245-7
30
1.880
[47.75]
1.400
[35.56]
6-102802-6
5-102589-4
5-534245-2
36
2.180
[55.37]
1.700
[43.18]
5-102802-3
5-102589-2
5-534245-8
40
2.380
[60.45]
1.900
[48.26]
5-102802-8
6-102589-3
—
50
2.880
[73.15]
2.400
[60.96]
5-102802-4
5-102589-5
5-534245-1
60
3.380
[85.85]
2.900
[73.66]
5-102802-9
5-102589-7
—
72
3.980
[101.09]
3.500
[88.90]
6-102802-7
6-102589-7
—
80
4.380
[111.25]
3.900
[99.06]
5-102802-5
5-102589-1
6-534245-0
90
4.880
[123.95]
4.400
[111.76]
6-102802-0
6-102589-4
—
100
5.380
[136.65]
4.900
[124.46]
5-102802-6
5-102589-3
6-534245-1
120
6.380
[162.05]
5.900
[149.86]
5-102802-2
6-102589-1
5-534245-3
130
6.880
[174.75]
6.400
[162.56]
6-102802-9
6-102589-9
6-534245-3
Note:
Headers with make first/break last posts can be made available, consult Tyco Electronics.
No. of
Pos.
Dimensions
Note:
All part numbers are RoHS compliant.
200
Catalog 1307819
Revised 8-08
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
