2SD1583-ZK

Description
Power Bipolar Transistor, 3A I(C), 20V V(BR)CEO, 1-Element, NPN, Silicon, TO-252AA, Plastic/Epoxy, 2 Pin, TO-252, MP-3Z, 3 PIN
CategoryDiscrete semiconductor    The transistor
File Size2MB,4 Pages
ManufacturerNEC Electronics
Download Datasheet Parametric Compare View All

2SD1583-ZK Overview

Power Bipolar Transistor, 3A I(C), 20V V(BR)CEO, 1-Element, NPN, Silicon, TO-252AA, Plastic/Epoxy, 2 Pin, TO-252, MP-3Z, 3 PIN

2SD1583-ZK Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerNEC Electronics
package instructionSMALL OUTLINE, R-PSSO-G2
Contacts3
Reach Compliance Codecompliant
ECCN codeEAR99
Shell connectionCOLLECTOR
Maximum collector current (IC)2 A
Collector-emitter maximum voltage20 V
ConfigurationSINGLE
Minimum DC current gain (hFE)1600
JESD-30 codeR-PSSO-G2
JESD-609 codee0
Number of components1
Number of terminals2
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeNPN
Certification statusNot Qualified
surface mountYES
Terminal surfaceTIN LEAD
Terminal formGULL WING
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
Nominal transition frequency (fT)270 MHz
Base Number Matches1
DATA SHEET
SILICON POWER TRANSISTOR
2SD1583-Z
NPN SILICON EPITAXIAL TRANSISTOR
DESCRIPTION
The 2SD1583-Z is designed for Audio Frequency Amplifier and
Switching, especially in Hybrid Integrated Circuits.
<R>
PACKAGE DRAWING (Unit: mm)
6.5 ±0.2
5.0 ±0.2
4.4 ±0.2
5.5 ±0.2
1.5
−0.1
+0.2
Note
5.6 ±0.3
9.5 ±0.5
• High h
FE
: h
FE
= 800 to 3200
• Low V
CE(sat)
: V
CE(sat)
= 0.18 V TYP.
1 2 3
0.5 ±0.1
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Collector to Base Voltage
Collector to Emitter Voltage
Base to Emitter Voltage
Collector Current (DC)
Collector Current (pulse)
Note 1
Note 2
2.3 ±0.3
30
20
5
2
3
2.0
150
V
V
V
A
A
W
°C
°C
TO-252 (MP-3Z)
2.3 ±0.3
0.15 ±0.15
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
P
T
T
j
T
stg
1.
2.
3.
4.
Base
Collector
Emitter
Collector Fin
Total Power Dissipation (T
A
= 25°C)
Junction Temperature
Storage Temperature
Note
The depth of notch at the top of the fin is
from 0 to 0.2 mm.
−55
to +150
Notes 1.
PW
10 ms, Duty Cycle
50%
2.
When mounted on ceramic substrate of 7.5 cm
2
× 0.7 mm
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. D18289EJ3V0DS00 (3rd edition)
(Previous No. TC-1671A)
Date Published July 2006 NS CP(K)
Printed in Japan
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
1.0 ±0.5
0.4 MIN.
0.5 TYP.
2.5 ±0.5
FEATURES
4
2.3 ±0.2
0.5 ±0.1
Note
0.5 ±0.1
1985, 2006

2SD1583-ZK Related Products

2SD1583-ZK 2SD1583-ZM 2SD1583-Z 2SD1583-ZL
Description Power Bipolar Transistor, 3A I(C), 20V V(BR)CEO, 1-Element, NPN, Silicon, TO-252AA, Plastic/Epoxy, 2 Pin, TO-252, MP-3Z, 3 PIN Power Bipolar Transistor, 3A I(C), 20V V(BR)CEO, 1-Element, NPN, Silicon, TO-252AA, Plastic/Epoxy, 2 Pin, TO-252, MP-3Z, 3 PIN Power Bipolar Transistor, 3A I(C), 20V V(BR)CEO, 1-Element, NPN, Silicon, TO-252AA, Plastic/Epoxy, 2 Pin, TO-252, MP-3Z, 3 PIN Power Bipolar Transistor, 3A I(C), 20V V(BR)CEO, 1-Element, NPN, Silicon, TO-252AA, Plastic/Epoxy, 2 Pin, TO-252, MP-3Z, 3 PIN
package instruction SMALL OUTLINE, R-PSSO-G2 SMALL OUTLINE, R-PSSO-G2 SMALL OUTLINE, R-PSSO-G2 SMALL OUTLINE, R-PSSO-G2
Reach Compliance Code compliant compliant unknown compliant
Shell connection COLLECTOR COLLECTOR COLLECTOR COLLECTOR
Maximum collector current (IC) 2 A 2 A 3 A 2 A
Collector-emitter maximum voltage 20 V 20 V 20 V 20 V
Configuration SINGLE SINGLE SINGLE SINGLE
Minimum DC current gain (hFE) 1600 800 500 1000
JESD-30 code R-PSSO-G2 R-PSSO-G2 R-PSSO-G2 R-PSSO-G2
Number of components 1 1 1 1
Number of terminals 2 2 2 2
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE
Polarity/channel type NPN NPN NPN NPN
Certification status Not Qualified Not Qualified Not Qualified Not Qualified
surface mount YES YES YES YES
Terminal form GULL WING GULL WING GULL WING GULL WING
Terminal location SINGLE SINGLE SINGLE SINGLE
transistor applications SWITCHING SWITCHING SWITCHING SWITCHING
Transistor component materials SILICON SILICON SILICON SILICON
Nominal transition frequency (fT) 270 MHz 270 MHz 270 MHz 270 MHz
Base Number Matches 1 1 1 1
Is it Rohs certified? incompatible incompatible - incompatible
Maker NEC Electronics NEC Electronics - NEC Electronics
Contacts 3 3 - 3
ECCN code EAR99 EAR99 - EAR99
JESD-609 code e0 e0 - e0
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED - NOT SPECIFIED
Terminal surface TIN LEAD TIN LEAD - TIN LEAD
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED - NOT SPECIFIED
