536457-5

Description
CONNECTOR, 64 CONTACT(S), FEMALE, STRAIGHT TWO PART EURO CONNECTOR, SOLDER, RECEPTACLE
CategoryThe connector    The connector
File Size103KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

536457-5 Overview

CONNECTOR, 64 CONTACT(S), FEMALE, STRAIGHT TWO PART EURO CONNECTOR, SOLDER, RECEPTACLE

536457-5 Parametric

Parameter NameAttribute value
Reach Compliance Codeunknow
Other featuresSTANDARD: DIN 41612
Body/casing typeRECEPTACLE
Connector typeBOARD EURO CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderFEMALE
DIN complianceYES
Filter functionNO
IEC complianceNO
MIL complianceNO
Manufacturer's serial number536457
Mixed contactsNO
Installation methodSTRAIGHT
Installation typeBOARD
Number of rows loaded2
OptionsGENERAL PURPOSE
Terminal pitch2.54 mm
Termination typeSOLDER
Total number of contacts64
UL Flammability Code94V-0
Base Number Matches1

Preview

Download Datasheet
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Eurocard C onnectors
>
Product Feature Selector
> Product Details
536457-5 Product Details
Live Product Chat
Product Photo
Eurocard Type B
5 of 6 EU R oHS/ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
View Mating Products (6)
Product Feature Selector
C ontact Us About This Product
536457-5
T E I nternal N umber: 5 3 6 4 5 7 - 5
Product Highlights:
l
Mating Type = Receptacle
l
Number of Positions = 64
l
PC B Mount Angle = Vertical
l
Post Type = Solder Post
l
Not Make First / Break Last
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Obsolete
C ontact Product Information C enter
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
l
Mating Products (6)
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Mating Type
= Receptacle
l
Number of Positions
= 64
l
PC B Mount Angle
= Vertical
l
Post Type
= Solder Post
l
Make First / Break Last
= No
l
Bus Type
= C IMBUS, STE Bus
l
DIN Level
= II
l
Size
= Standard
l
PC B Retention Feature
= Yes
l
C olor = Gray
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.30 [0.130]
Body Related Features:
l
C ontact C ross Section (mm [in])
= 0.30 x 0.61 [.012 x .024]
l
PC B Retention Method
= Boardlock(s)
l
Rows Loaded = A, B
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polyester
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
l
Flux-Tight C oating
= Without
Conditions for Usage:
l
Terminate To = Printed C ircuit Board
Other:
l
Brand = AMP
