82723 Paired - Double-Pair Cable
For more information please
call
1-800-Belden1
See Put-ups and Colors
Description:
22 AWG stranded (7x30) TC conductors, plenum, FEP insulation, twisted pairs, individually shielded w/Beldfoil® (100% coverage), 22
AWG stranded TC drain wire, Flamarrest® jacket.
PHYSICAL CHARACTERISTICS:
CONDUCTOR:
Number of Pairs
Total Number of Conductors
AWG
Stranding
Conductor Material
INSULATION:
Insulation Material
Lay Length
Twists/ft.
Pair Color Code Chart :
Number
1
INNER SHIELD:
Inner Shield Material Trade Name
Inner Shield Type
Inner Shield Material
Inner Shield % Coverage
Inner Shield Drain Wire AWG
Inner Shield Drain Wire Stranding
Inner Shield Drain Wire Conductor Material
OUTER SHIELD:
Outer Shield Material
OUTER JACKET:
Outer Jacket Material Trade Name
Flamarrest®
Page 1 of 3
2
4
22
7x30
TC - Tinned Copper
FEP - Fluorinated Ethylene Propylene
1.5 in.
8
Color
Red & Black
Number
2
Color
Green & White
Beldfoil® (Z-Fold®)
Tape
Aluminum Foil-Polyester Tape
100 %
24
7x32
TC - Tinned Copper
Unshielded
82723 Paired - Double-Pair Cable
Outer Jacket Material
OVERALL NOMINAL DIAMETER:
Overall Nominal Diameter
MECHANICAL CHARACTERISTICS:
Operating Temperature Range
Bulk Cable Weight
Max. Recommended Pulling Tension
Min. Bend Radius (Install)
LS PVC - Low Smoke Polyvinyl Chloride
.153 in.
0°C To +75°C
17.5 lbs/1000 ft.
46 lbs.
1.5 in.
APPLICABLE SPECIFICATIONS AND AGENCY COMPLIANCE:
APPLICABLE STANDARDS:
NEC/(UL) Specification
CEC/C(UL) Specification
EU CE Mark (Y/N)
EU RoHS Compliant (Y/N)
EU RoHS Compliance Date (mm/dd/yyyy):
FLAME TEST:
UL Flame Test
C(UL) Flame Test
PLENUM/NON-PLENUM:
Plenum (Y/N)
Non-Plenum Number
ELECTRICAL CHARACTERISTICS:
Nom. Characteristic Impedance
Nom. Capacitance Conductor to Conductor @ 1 KHz
Nom. Cap. Cond. to Other Cond. & Shield @ 1 KHz
Nominal Velocity of Propagation
Nom. Conductor DC Resistance @ 20 Deg. C
Nom. Inner Shield DC Resistance
Max. Operating Voltage - UL
Max. Recommended Current
36 Ohms
43 pF/ft
75 pF/ft
62 %
14.7 Ohms/1000 ft
15 Ohms/1000 ft
300 V RMS
2.3 Amps per conductor @25°C
Y
8723
NFPA 262
FT6
CMP
CMP
Yes
Yes
04/01/2005
PUT-UPS AND COLORS:
Item
Description
82723 8771000
2 PR #22 FEP FS
FLRST
82723 877U1000
2 PR #22 FEP FS
FLRST
Put-Up (ft.)
1000
U1000
Ship Weight (lbs.)
19
20
Page 2 of 3
Jacket Color
NATURAL
NATURAL
Notes
C
82723 Paired - Double-Pair Cable
82723 877U2000
82723 877U500
2 PR #22 FEP FS
FLRST
2 PR #22 FEP FS
FLRST
U2000
U500
40
10.5
NATURAL
NATURAL
C = CRATE REEL PUT-UP.
Revision Number: 1
Revision Date: 07-27-2005
© 2005 Belden Wire & Cable Company
All Rights Reserved.
Although Belden Electronics Division ("Belden") makes every reasonable effort to ensure their accuracy at the time of this publication,
information and specifications described herein are subject to error or omission and to change without notice, and the listing of such
information and specifications does not ensure product availability.
Belden provides the information and specifications herein on an "AS IS" basis, with no representations or warranties, whether express,
statutory or implied. In no event will Belden be liable for any damages (including consequential, indirect, incidental, special, punitive, or
exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract,
negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described
herein.
All sales of Belden products are subject to Belden's standard terms and conditions of sale.
Belden CDT Electronics Division believes this product to be in compliance with the following environmental regulations: California
Proposition 65 Consent Judgment For Wire & Cable Mfgs.(San Francisco Superior Court Nos. 312962 And 320342); EU RoHS
(Directive 2002/95/EC, 27-Jan-2003);Material manufactured prior to the compliance date may still be in stock at Belden facilities and in our
Distributor's inventory. EU ELV (Directive 2000/53/EC, 18-Sept-2000); EU WEEE (Directive 2002/96/EC, 27-Jan-2003); And EU BFR
(Directive 2003/11/EC, 6-Feb-2003). The information provided in this Product Disclosure, and the identification of materials listed as
reportable or restricted within the Product Disclosure, is correct to the best of Belden's knowledge, information and belief at the date of its
publication. The information provided in the Product Disclosure is designed only as a general guide for the safe handling, storage, and any
other operation of the product itself or the one that it becomes a part of. This Product Disclosure is not to be considered a warranty or quality
specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of
legislation and regulations based on their individual usage of the product.
Belden CDT Electronics Division declares this product to be in compliance with EU LVD (Low Voltage Directive 73/23/EEC), as amended
by directive 93/68/EEC.
Page 3 of 3
