HIGH SPEED PNP
SILICON BIPOLAR TRANSISTOR
2N2894AC1
•
•
•
•
Hermetic Ceramic Surface Mount Package (SOT23 Compatible)
Silicon Planar Epitaxial PNP Transistor
High Speed low Saturation Switching
Space Level and High-Reliability Screening Options Available
ABSOLUTE MAXIMUM RATINGS
(TA = 25°C unless otherwise stated)
VCBO
VCEO
VEBO
IC
PD
TJ
Tstg
Collector – Base Voltage
Collector – Emitter Voltage
Emitter – Base Voltage
Continuous Collector Current
TA = 25°C
Total Power Dissipation at
Derate Above 25°C
Junction Temperature Range
Storage Temperature Range
-12V
-12V
-4.5V
-200mA
360mW
2.88mW/°C
-65 to +150°C
-65 to +150°C
THERMAL PROPERTIES
Symbol
R
θJA
Parameter
Thermal Resistance Junction to Ambient
Max
347
Units
°C/W
Semelab Limited reserves the right to change test conditions, parameter limits and package dimensions without notice.
Information furnished by Semelab is believed to be both accurate and reliable at the time of going to press. However
Semelab assumes no responsibility for any errors or omissions discovered in its use. Semelab encourages customers to
verify that datasheets are current before placing an order.
Semelab Limited
Telephone +44 (0) 1455 556565
Email:
sales@semelab-tt.com
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Fax +44 (0) 1455 552612
Website:
http://www.semelab-tt.com
Document Number 8519
Issue 1
Page 1 of 4
HIGH SPEED PNP
SILICON BIPOLAR TRANSISTOR
2N2894AC1
ELECTRICAL CHARACTERISTICS
(TA = 25°C unless otherwise stated)
Symbols
V(BR)CBO
V(BR)CEO
V(BR)EBO
ICBO
(1)
(1)
Parameters
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cut-Off Current
Test Conditions
IC = -10µA
IC = -10mA
IE = -100µA
VCB = -10V
IE = 0
IB = 0
IC = 0
IE = 0
TA = 125°C
IC = -10mA
VCE = -0.3V
VCE = -0.5V
TA = -55°C
IC = -100mA
IC = -10mA
VCE = -1.0V
IB = -1.0mA
IB = -3.0mA
IB = -10mA
IB = -1.0mA
IB = -3.0mA
IB = -10mA
Min
-12
-12
-4.5
Typ
Max
Units
V
(1)
-100
-10
30
40
20
30
-0.15
-0.19
-0.45
-0.98
-1.15
-1.50
120
nA
µA
hFE
(1)
Forward-current transfer ratio
IC = -30mA
VCE(sat)
(1)
Collector-Emitter Saturation Voltage
IC = -30mA
IC = -100mA
IC = -10mA
V
VBE(sat)
(1)
Base-Emitter Saturation Voltage
IC = -30mA
IC = -100mA
V
DYNAMIC CHARACTERISTICS
fT
COBO
CIBO
ton
toff
Current Gain-Bandwidth Product
Output Capacitance
Input Capacitance
Turn-On Time
Turn-Off Time
IC = -30mA
f = 100MHz
VCB = -5V, IE = 0, 1.0MHz
VEB = -0.5V, IC = 0, 1.0MHz
VCC = -2V
IB1 = 1.5mA
IC = -30mA
IB2 = -1.5mA
4.5
6.0
60
60
ns
pF
VCE = -10V
650
MHz
Notes
(1) Pulse Width < 300µs, Duty Cycle <2%
Semelab Limited
Telephone +44 (0) 1455 556565
Email:
sales@semelab-tt.com
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Fax +44 (0) 1455 552612
Website:
http://www.semelab-tt.com
Document Number 8519
Issue 1
Page 2 of 4
HIGH SPEED PNP
SILICON BIPOLAR TRANSISTOR
2N2894AC1
SCREENING OPTIONS
Space Level (JQRS/ESA) and High Reliability options are
available in accordance with the
High Reliability and
Screening Options Handbook
available for download from
the from the TT electronics Semelab web site.
ESA Quality Level Products are based on the testing
procedures specified in the generic ESCC 5000 and in the
corresponding part detail specifications.
Semelabs QR216 and QR217 processing specifications
(JQRS), in conjunction with the companies ISO 9001:2000
approval present a viable alternative to the American MIL-
PRF-19500 space level processing.
QR217 (Space Level Quality Conformance) is based on the
quality conformance inspection requirements of MIL-PRF-
19500 groups A (table V), B (table VIa), C (table VII) and
also ESA / ESCC 5000 (chart F4) lot validation tests.
QR216 (Space Level Screening) is based on the screening
requirements of MIL-PRF-19500 (table IV) and also ESA
/ESCC 5000 (chart F3).
JQRS parts are processed to the device data sheet and
screened to QR216 with conformance testing to Q217
groups A and B in accordance with MIL-STD-750 methods
and procedures.
Additional conformance options are available, for example
Pre-Cap Visual Inspection, Buy-Off Visit or Data Packs.
These are chargeable and must be specified at the order
stage (See Ordering Information). Minimum order
quantities may apply.
Alternative or additional customer specific conformance or
screening requirements would be considered. Contact
Semelab sales with enquires.
ORDERING INFORMATION
Part numbers are built up from Type, Package Variant, and
screening level. The part numbers are extended to include
the additional options as shown below.
Type – See Electrical Stability Characteristics Table
Package Variant – See Mechanical Data
Screening Level – See Screening Options (ESA / JQRS)
Additional Options:
Customer Pre-Cap Visual Inspection
Customer Buy-Off visit
Data Pack
Solderability Samples
Scanning Electron Microscopy
Radiography (X-ray)
Total Dose Radiation Test
MIL-PRF-19500 (QR217)
Group B charge
Group B destructive mechanical samples
Group C charge
Group C destructive electrical samples
Group C destructive mechanical samples
ESA/ESCC
Lot Validation Testing (subgroup 1) charge
LVT1 destructive samples (environmental)
LVT1 destructive samples (mechanical)
Lot Validation Testing (subgroup 2) charge
LVT2 endurance samples (electrical)
Lot Validation Testing (subgroup 3) charge
LVT3 destructive samples (mechanical)
.CVP
.CVB
.DA
.SS
.SEM
.XRAY
.RAD
.GRPB
.GBDM (12 pieces)
.GRPC
.GCDE (12 pieces)
.GCDM (6 pieces)
.LVT1
.L1DE (15 pieces)
.L1DM (15 pieces)
.LVT2
.L2D (15 pieces)
.LVT3
.L3D (5 pieces)
Additional Option Notes:
1) All ‘Additional Options’ are chargeable and must be specified at order stage.
2) When Group B,C or LVT is required, additional electrical and mechanical destructive
samples must be ordered
3) All destructive samples are marked the same as other production parts unless
otherwise requested.
MARKING DETAILS
Parts can be marked with approximately 8 characters on
two lines and can include the cathode identification.
Typical marking would include part or specification number,
week of seal or serial number subject to available space and
legibility.
Customer specific marking requirements can be arranged at
the time of order.
Example Marking:
Example ordering information:
The following example is for the 2N2894AC1 part with
package variant B, JQRS screening, additional Group C
conformance testing and a Data pack.
Part Numbers:
2N2894AC1B-JQRS
(Include quantity for flight parts)
2N2894AC1B.GRPC
(chargeable conformance option)
2N2894AC1B.GCDE
(charge for destructive parts)
2N2894AC1B.GCDM
(charge for destructive parts)
2N2894AC1B.DA
(charge for Data pack)
Customers with any specific requirements (e.g. marking or
screening) may be supplied with a similar alternative part
number (there is maximum 20 character limit to part
numbers). Contact Semelab sales with enquiries.
High Reliability and Screening Options Handbook link:
http://www.semelab.co.uk/pdf/misc/documents/hirel_and_screening_options.pdf
Semelab Limited
Telephone +44 (0) 1455 556565
Email:
sales@semelab-tt.com
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Fax +44 (0) 1455 552612
Website:
http://www.semelab-tt.com
Document Number 8519
Issue 1
Page 4 of 4
