ATTENUATORS
Type N, up to 6 GHz, 1 Watts
00
SPECIFICA
TIONS:
Models: XN100W-XX, XN100W-XXF & XN100W-XXM
Electrical:
Frequency Range
Standard Freq. Values
Standard dB Values
Attenuation Accuracy
3 & 6 dB
10 dB
20 & 30 dB
40 dB
VSWR (Max.)
Input Power
Reverse Power
Peak Power
Impedance
Operating Temp Range
DC - 6.0 GHz
2.5 & 6 GHz
3, 6, 10, 20, 30 & 40 dB
2.5 - 6 GHz
1.5 - 2.5 GHz
±0.75 dB
±0.50 dB
±2.50 dB
±0.75 dB
±0.75 dB
±1.50 dB
±1.50 dB
±2.50 dB
1.35:1
1.45:1
100 Watts Avg.
Derated Linearly to 20 Watts @ +1 C
25
o
DC - 1.5 GHz
±0.50 dB
±0.75 dB
±0.75 dB
±1.50 dB
1.25:1
Custom Mtg. hole Config.
may be Added to this
Surface
20 Watts Max.
1 kW Max.
(5uSec Pulse, .05% Duty Cycle)
3.46±.02
[87.88±0.51]
SQUARE
50 Ohms
-55°C to +1
25°C
Passivated Stainless Steel
Gold Plated Beryllium Copper
Anodized Aluminum
Mechanical:
Type N Connectors
Mates with MIL
-STD-348
END VIEW
T YPICAL
Units must be Mounted in such a way as to
Allow for Free Air Flow Around fins to Assure
Performance
Conductors
Housing
Note: Units are Unidirectional, Therefore Input Connector MUST be specified & will be Indicated on Unit
Model Number:
XN1
00W-XX
Male/Female Connectors
Length: 6.36 –.05 [1 1 –1
6 .5 .3]
Pictured
INPUT
6.36 ±.05
[161.5 ±1.3]
1.75
[44.45]
00W-XXF
Model Number:
XN1
Female/Female Connectors
Length: 6.45 –.05 [1
63.8 –1
.3]
00W-XXM
Model Number:
XN1
Male/Male Connectors
Length: 6.28 –.05 [1
59.5 –1
.3]
.23 [5.84]
2X M4x0.7 T
AP
x .50 [12.7] DP
.
2X 8-32UNC-2B T
AP
x .50 [12.7] DP
.
HOW TO ORDER:
Model Number:
Ordering Examples:
Model Number:
2N100W-01
DC - 2.5 GHz, 1 dB; Type N - Male/Fem
Connector Configuration
= Male/Female
(Male Input)
F = Fem/Fem
M = Male/Male
FM = Female/Male
(Female Input)
Model Number:
2N100W-03F
DC - 2.5 GHz, 3 dB; Type N - Fem/Fem
Model Number:
6N100W-20FM
DC - 6 GHz, 20 dB; Type N - Female/Male
XN100W-XXY
Freq. Range
2 = DC - 2.5 GHz
6 = DC - 6 GHz
dB Value
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design specifications are subject to change without notice.
Contact factory for technical specifications before purchasing or use.
XN100W-A : REV P
TT
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex.com/inmet • inmetsales@aeroflex.com
