AK60A-048L-050F10 datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> AK60A-048L-050F10

AK60A-048L-050F10: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid; CategoryPower/power management The power supply circuit; File Size241KB，21 Pages; ManufacturerArtysen Embedded Technologies

Download Datasheet Parametric View All

AK60A-048L-050F10 Overview

DC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid

AK60A-048L-050F10 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Certification	UL; CSA; VDE; CE
Efficiency (main output)	83%
Maximum input voltage	72 V
Minimum input voltage	36 V
Nominal input voltage	48 V
JESD-30 code	R-XXMA-X
JESD-609 code	e0
Number of functions	1
Output times	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-20 °C
Maximum output voltage	5.5 V
Minimum output voltage	4.5 V
Nominal output voltage	5 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Protect	THERMAL; CURRENT; OUTPUT OVER VOLTAGE
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal surface	TIN LEAD
Terminal form	UNSPECIFIED
Terminal location	UNSPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	50 W
Fine-tuning/adjustable output	YES
Base Number Matches	1

Preview

Download Datasheet

View All

For further information contact :

NORTH AMERICA

ASTEC AMERICA, INC,.

6339 Paseo Del Lago,

Carlsbad CA 92009,

USA.

Tel : 760-757-1880

Fax : 760-930-4700

EUROPE

ASTEC EUROPE LTD.

High Street,Wollaston,

Stourbridge,

West Midlands,

DY8 4PG

U.K.

Tel : 01384-440044

Fax : 01384-440777

ASIA

ASTEC POWER SYSTEMS

6th Floor, CDW Building,

382-392 Castle Peak Road,

Tsuen Wan,

N.T.

Hong Kong

Tel : 852 24117429

Fax : 852 24113610

APA701-AK60 Rev. 02 May 97

Contents

AK60A Economy Series

Introduction ...................................................................................................... 2

Special Features .............................................................................................. 2

Ordering Information ........................................................................................ 3

Safety ............................................................................................................... 3

Electrical Specifications .................................................... 4

Absolute Maximum Ratings – all models ......................................................... 4

Pin Connections - all models ............................................................................ 5

Electrical Specifications for 24V Input Models (AK60A-024L-xxxFyy) ............. 6

Insulation - all models ...................................................................................... 6

Electrical Specifications for 48V Input Models (AK60A-048L-xxxFyy) ............. 8

Functional Description .................................................... 10

Remote Sense (+SENSE, -SENSE) .............................................................. 10

Enable Control (ENABLE) .............................................................................. 10

PRI AUX ......................................................................................................... 10

CLK IN ............................................................................................................ 11

Output Voltage Adjustment (V ADJ) ............................................................... 12

Signal Common (S COM) .............................................................................. 12

Design Considerations .................................................... 13

Input Bulk Capacitors ..................................................................................... 13

Remote Loads ................................................................................................ 13

Input Undervoltage Protection ........................................................................ 13

Conducted EMI .............................................................................................. 13

Output Ripple and Noise ................................................................................ 13

Input Fusing ................................................................................................... 13

Break Regulation ............................................................................................ 14

Overtemperature Protection ........................................................................... 14

MTBF ............................................................................................................. 14

Thermal Data ................................................................................................. 14

Application Example ........................................................ 15

Mechanical Information ................................................... 16

Dimensions .................................................................................................... 16

Recommended PCB Layout ........................................................................... 17

Heatsink Mounting Information ...................................................................... 18

AMPSS

Reference Manual

Rev. 02 May 97
