FUSEHOLDERS
FOR 3AG, 5 x 20mm, OR MIDGET FUSES
Shock-Safe for 3AG or 5x20mm Fuses
PC Board Type
Similar to Shock-Safe fuseholders shown on preceding
page, but designed for P.C. board mounting. Shock-Safe
design per IEC Standards 60127 and 60065. Two different
knob styles available for use with 3AG (
1
/
4
" x 1
1
/
4
") or
5 x 20mm fuses.
APPROVALS:
Recognized under the Components Program
of Underwriters Laboratories (16A, 250V).
Certified by CSA (15A, 250V).
SEMKO approved (6.3A, 250V).
VDE approved (10A, 250V).
SPECIFICATIONS:
Electrical:
Rating: See APPROVALS.
Insulation Resistance:
10,000 megohm minimum at
500 VDC.
Contact Resistance:
Less than .005 ohm average at a
current of one ampere.
Dielectric Strength:
4000 volts minimum.
Mounting:
Intended for soldering to printed circuit boards.
Molded Parts:
Body Material: Black glass-filled thermoplas-
tic (UL 94V0).
Knob:
Screwdriver slot, fuse extractor type with nickel-
plated, copper alloy insert. Spring-loaded, bayonet style.
Knob Material:
Grey or Black glass-filled thermoplastic
(UL 94V0).
Terminals:
Brass. Tin-plated.
Ambient Temperature:
–40°C to +85°C.
®
®
D
V
E
Reference Dimensions
1.77"
.44"
.49"
ORDERING INFORMATION:
Catalog
Number
345
101
345
121
Body only:
345
101-010
Knob only:
345
101-020 (
1
/
4
" x 1
1
/
4
") Grey;
345
121-020 (5 x 20mm) Black.
yy
;;
.68"
.20"
.24"
.598"
.602"
.698"
.702"
.86"
.92"
DIA.
2.08"
2.40"
.76"
1.31"
1.75"
.15" MAX
.890"
1.310"
.48"
.12"
.040"
.242"
.246"
.056"
DIA.
Fuse
Size
1
/
4
" x 1
1
/
4
" Fuses
5 x 20mm Fuses
for Midget Fuses
Panel Mount Type
Two panel mount fuseholder designs are available for sup-
plementary or Class CC branch circuit protection. Class CC
fuses have a rejection feature on one end cap which mates
with the rejection feature of Littelfuse Class CC fuse blocks
and fuseholders to prevent the installation of fuses with
lower voltage ratings or interrupting ratings.
APPROVALS:
Recognized under the Components Program
of Underwriters Laboratories and Certified by CSA.
SPECIFICATIONS:
Electrical:
Rated at 30 amperes for any voltage up to
600 volts.
Dielectric Strength:
4000 volts minimum.
Mounting:
Flange mounting either in front of or behind
panel. Watertight version must be front panel mounted.
Maximum panel thickness is .75".
Molded Parts:
Black thermoplastic (UL 94V0).
Knob:
Screw type, with engraved markings: unfilled
characters (571 007,
571
008,
571
007P,
571
008P), light
blue characters (571 027,
571
028,
571
027P,
571
028P).
Terminals:
Brass. Tin-plated. Combination solder and
1
/
4
"
Quick-Connect. Side terminal has .125" diameter hole.
Bottom terminal has .156" x .124" elongated hole.
Ambient Temperature:
– 40°C to +85°C.
Hardware: 571
007,
571
008,
571
027,
571
028,
571
OCC,
and
571
RCC, none;
571
007P,
571
008P,
571
027P,
571
028P,
571
OCCP, and
571
RCCP, two O-rings for
watertight seal per MIL-PRF-19207.
®
®
Reference Dimensions
.15" MAX
1.72" DIA.
(2)
1.12"
.032"
STANDARD MOUNTING
(FLANGE IN FRONT OF PANEL)
2 MOUNTING
HOLES FOR
No. 8 SCREWS
.446"
ORDERING INFORMATION:
Catalog Number
Standard
Watertight
571
027
571
027P
571
028
571
028P
571
007
571
007P
571
008
571
008P
571
OCC
571
OCCP
571
RCC
571
RCCP
*Fuse diameter is
13
/
32
".
Bottom
Terminal
Straight
Rt. Angle
Straight
Rt. Angle
Straight
Rt. Angle
Fuse Length
Range*
1
5
/
16
" – 1
3
/
8
"
1
13
/
32
" – 1
1
/
2
"
1
1
/
2
"
98
