UBMINIATURE
S
UBMINIATURE
F
USEHOLDERS
Holder / No. 570
Panel Mount,
for TR5
®
/TE5
®
Fuses
Cap
TR5 Fuse
∅
15
M12,7x1,5
Specifications
Packaging
000
bulk (100 pcs.)
Order Number
Holder
No. 570 0000 000
Mounting
12.7mm diameter D-hole or double D-hole
Admissible torque on plastic hex nut is 1.2Nm
17,9
10
SW14
14,2
1,6 3,2
Te r m i n a l s
Solderable or 2.8mm quick connect-fits 0.5mm tab
Materials
Holder:
Black Thermoplastic, UL 94 V-0
Polyamide PA 6.6
Copper alloy
Solderable tinned
0,5
2,8
1,8
Metal parts:
5,08
Hole
9,6
M12,7x1,5
11,7 -0,15
Electrical Data (23ºC/without Cap)
Rated Voltage:
250V
Max. Current/Power: 6.3A/2.5W
Minimum Cross Section
Conductor - 2.5mm 2
Unit Weight
2.2g
12 -0,1
12,7 -0,1
12,7 -0,1
Panel alternatives
with cap 575 IP40
(only on front side)
Order
Information
Qty.
Order-
Number
Series
570
0000
Packaging
000
Packaging
000
Order
Cap
Specifications are subject
to change without notice
Cap / No. 575
∅
15
10
bulk (100 pcs.)
Number
No. 575 0000 000
Plastic Cap
Use with No. 570 or No. 571
Materials
Cap:
Transparent Thermoplastic
Polycarbonat PC, UL94 V-0
M12,7x1,5
Order
Information
Qty.
Order-
Number
Series
575
Unit Weight
0.94g
0000
Packaging
000
Packaging
000
Specifications are subject
to change without notice
Holder / No. 571
PC Mount, for TR5
®
/TE5
®
Fuses
7,62
bulk (100 pcs.)
Order Number
Holder
No. 571 0000 000
Mounting
PC Board, 7.62mm hole spacing
TR5 Fuse
∅
15
M12,7x1,5
Cap
10
Materials
Holder:
17,9
11,5
Metal parts:
Black Thermoplastic, UL94 V-0
Polyamide PA 6.6
Copper alloy
Solderable, tinned
Holes in PCB
1,3 +0,1
0,5
1,1 +0,1
7,62
Electrical Data (23ºC/without Cap)
Rated Voltage:
250V
Max. Current/Power: 6.3A/2.5W
Minimum Cross Section
Conducting path - 0.2mm
2
Unit Weight
1.6g
5
M12,7x1,5
Order
Information
Qty.
Order-
Number
Series
571
0000
Packaging
000
Specifications are subject
to change without notice
Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
In our continuing strategy to deliver unparalleled circuit protection solutions,
technical expertise and application leadership, we proudly introduce the
WICKMANN Group and its products to the Littelfuse portfolio.
050909
