mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
Type
with lift system
11
Additional Centerline
Type 11
Type 71
Voltage
71
300 V - centerline 5 mm
600 V - centerline 10 mm
15 A
12 - 28 AWG
# (see note)
8 lbs. - in
.8 mm x 1 mm
1.4 mm
7 mm
Voltage
with lift system
Electrical Data
Electrical Data
300 V - centerline 5 mm
600 V - centerline 10 mm
20 A
12 - 22 AWG
## (see note)
6 lbs. - in
.8 mm x 1 mm
1.4 mm
8 mm
Modular Types
similar to
Type 11
Type 12
similar to
Type 71
Type 72
Page DA-19
Page DA-19
Current
Wire Range
Screw torque
Square pin
PCB hole diameter
Wire strip length
Current
Wire Range
Screw torque
Square pin
PCB hole diameter
Wire strip length
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, nickel plated
brass, tin over nickel plating
M3, steel
nickel over copper plating
2 to 16 - centerline 5 mm
2 to 8 - centerline 10 mm
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, nickel plated
brass, tin over nickel plating
M3, steel
nickel over copper plating
optional: stainless steel
- consult factory
2 to 24 - centerline 5 mm
2 to 12 - centerline 10 mm
Color
Terminal
Lift system
Screw
Pole sizes
Color
Terminal
Lift system
Screw
Pole sizes
Additional material data - pages DA-3 to DA-5
Additional material data - pages DA-3 to DA-5
D
Dimensions (mm)
Dimensions (mm)
Note for wire range
Additional wire sizes and/or
combinations of same size
wires as follows:
L = (circuits - 1) x centerline + 5
L = (circuits - 1) x centerline + 5
Part Numbers
Type 11
Complete the part number
by adding the pole size.
centerline 5 mm
Part Numbers
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
02 03 04 05 06 07 08
Type 11
#
1 No. 30 AWG
(Factory-wiring)
2 No. 22-16 AWG
(Field-wiring);
2 No. 30-16 AWG or
1 No. 30-12 AWG
(Factory-wiring)
Part No.
310111
Type 11
centerline 10 mm
Type 71
Complete the part number
by adding the pole size.
centerline 5 mm
Part No.
310711
Type 71
centerline 10 mm
Type 71
##
Part No.
310112
Part No.
310712
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
02 03 04 05 06 07 08
09 10 11 12
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
DA-16
