98
Headers
A
Type 249
page 148
page 144
page 143
page 144
page 147
page 148
page 146
page 150
page 146
page 150
Screw type terminal block, pluggable, centerline
5.08 mm / 0.200 inches, wire entry parallel to plug
direction, lift system, contact system with integrated
wire protection
Type 250
Screw type terminal block, pluggable, centerline
5.08 mm / 0.200 inches, wire entry parallel to plug
direction, lift system, contact system with integrated
wire protection, strain relief
to
Type 249
and
Type 250
Type 178
Type 179
Type 219
Type 220
Type 229
Type 230
Type 286
Type 288
Type 290
Type 292
Technical Data
V / A / AWG
V / A / AWG
300 / 16 / 28 - 12
300 / 16 / 28 - 12
Technical Data
V / A / AWG
300 / 16 / 28 - 12
0.08 - 2.5 mm² 250 V / 4 kV / 16 A
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 3.6 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
250
630
630
Rated test voltage
2.5
6
4
Protection category according
to IEC 529
IP20
Tightening torque UL
4.4 lb-in max.
Min. insul. strip length
8 mm
Pole size
3 - 12
Color
black
0.08 - 2.5 mm² 250 V / 4 kV / 16 A
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 3.6 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
250
630
630
Rated test voltage
2.5
6
4
Protection category according
to IEC 529
IP20
Tightening torque UL
4.4 lb-in max.
Min. insul. strip length
8 mm
Pole size
2 - 24
Color
black
Accessories
for
Type 249
and
Type 250
(only in combination with
headers type 178, 179, 219,
220, 229 and 230)
coding set
700025
page 206
Dimensions in mm
1 mm = 0.0394 in.
Dimensions in mm
1 mm = 0.0394 in.
L = (pole size - 1) x centerline + 5.08 mm / 0.200 inches
L = (pole size - 1) x centerline + 5.08 mm / 0.200 inches
Part numbers (P/N)
Type 249
centerline 5.08 mm / 0.200 inches
(information: page 56)
Complete the part number by
adding the pole size.
Part numbers (P/N)
Type 250
(information: page 56)
Complete the part number by
adding the pole size.
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
centerline 5.08 mm / 0.200 inches
03 04 05 06 07 08
09 10 11 12
P/N
312491
Type 249
centerline 10.16 mm / 0.400 inches
P/N
312501
02 03 04 05 06 07 08
09 10 11 12
P/N
312492
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
