mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Type
Type
with wire protection
03
Additional Centerline
Type 03
Type 05
Voltage
05
Voltage
with wire protection
wire entry 45°
Electrical Data
300 V - centerline 5 mm
600 V - centerline 10 mm
20 A
12 - 22 AWG
#, + (see note)
7 lbs. - in
1 mm
1.3 mm
8 mm
Electrical Data
300 V - centerline 5 mm
600 V - centerline 10 mm
15 A
12 - 22 AWG
#, + (see note)
6 lbs. - in
1 mm
1.3 mm
8 mm
Modular Type
similar to
Type 03
Type 81
Page DA-15
Current
Wire Range
Screw torque
Pin diameter
PCB hole diameter
Wire strip length
Current
Wire Range
Screw torque
Pin diameter
PCB hole diameter
Wire strip length
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, tin over nickel plating
tin bronze, tin plated
M3, steel
nickel over copper plating
optional: stainless steel
- consult factory
2 to 24 - centerline 5 mm
2 to 12 - centerline 10 mm
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, tin over nickel plating
tin bronze, tin plated
M3, steel
nickel over copper plating
optional: stainless steel
- consult factory
2 to 12 - centerline 5 mm
2 to 6 - centerline 10 mm
Color
Terminal
Wire protector
Screw
Color
Terminal
Wire protector
Screw
D
Pole sizes
Pole sizes
Additional material data - pages DA-3 to DA-5
Additional material data - pages DA-3 to DA-5
Dimensions (mm)
Note for wire range
Additional wire sizes and/or
combinations of same size
wires as follows:
Dimensions (mm)
Type 03
#
+
1 No. 30 AWG
(Factory-wiring);
2 No. 22-16 AWG
(Field-wiring);
2 No. 30-16 AWG
(Factory-wiring)
L = (circuits - 1) x centerline + 5
L = (circuits - 1) x centerline + 5
Part Numbers
Type 03
Complete the part number
by adding the pole size.
centerline 5 mm
Part Numbers
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
02 03 04 05 06 07 08
09 10 11 12
Type 05
Complete the part number
by adding the pole size.
centerline 5 mm
Type 05
#
+
1 No. 30 AWG
(Factory-wiring);
2 No. 22-16 AWG
(Field-wiring);
2 No. 30-16 AWG
(Factory-wiring)
Part No.
310031
Type 03
centerline 10 mm
Part No.
310051
Type 05
centerline 10 mm
02 03 04 05 06 07 08
09 10 11 12
02 03 04 05 06
Part No.
310032
Part No.
310052
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
DA-12
