148
Terminal blocks
A
Type 230
Header, centerline 5.08 mm / 0.200 inches, horizontal
mounting, square contact pins 1 mm / 0.039 inches,
closed ends, codable
Type 178
Header, centerline 5.08 mm / 0.200 inches, horizontal
mounting, designed for THR, optional Tape on Reel
packaging for automated processing, square contact
pins 1 mm / 0.039 inches, closed ends, codable
to
Type 230
and
Type 178
ASP046
Type 213
Type 214
Type 249
Type 250
page 50
page 100
page 100
page 98
page 98
Technical Data
V/A
V/A
300 / 15
300 / 15
250 V / 4 kV / 10 A
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 4.08 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
320
800
800
Rated test voltage
4
6
4
Protection category according
to IEC 529
IP00
Solder pin dimension
1.0 x 1.0 mm
Recommended pc board hole
dia.
Ø 1.5 mm
Solder pin length
3.45 mm
Pole size
2 - 24
Color
black
Technical Data
250 V / 4 kV / 10 A
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 4.08 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
320
800
800
Rated test voltage
4
6
4
Protection category according
to IEC 529
IP00
Solder pin dimension
1.0 x 1.0 mm
Recommended pc board hole
dia.
Ø 1.5 mm
Solder pin length
3.45 mm
Pole size
2 - 12
Color
black
Accessories
for
Type 230
and
Type 178
Coding set
700024
page 206
Note for Type 178
Packaging for automated
processing is available on
demand. Please do not hesi-
tate to contact us.
Dimensions in mm
1 mm = 0.0394 in.
Dimensions in mm
1 mm = 0.0394 in.
L = (pole size - 1) x centerline + 6.28 mm / 0.247 inches
L = (pole size - 1) x centerline + 6.28 mm / 0.247 inches
Part numbers (P/N)
Type 230
centerline 5.08 mm / 0.200 inches
(information: page 110)
Complete the part number by
adding the pole size.
Part numbers (P/N)
Type 178
(information: page 110)
Complete the part number by
adding the pole size.
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
centerline 5.08 mm / 0.200 inches
02 03 04 05 06 07 08
09 10 11 12
P/N
312301
Type 230
centerline 10.16 mm / 0.400 inches
P/N
311781
02 03 04 05 06 07 08
09 10 11 12
* approval pending
P/N
312302
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
