DDB6U215N16K Overview

Bridge Rectifier Diode, 3 Phase, 215A, 1600V V(RRM), Silicon, ISOPACK-14

DDB6U215N16K Parametric

Parameter Name	Attribute value
Maker	EUPEC [eupec GmbH]
package instruction	ISOPACK-14
Reach Compliance Code	unknown
Shell connection	ISOLATED
Configuration	BRIDGE, 6 ELEMENTS
Diode component materials	SILICON
Diode type	BRIDGE RECTIFIER DIODE
JESD-30 code	R-XUFM-X14
Maximum non-repetitive peak forward current	1950 A
Number of components	6
Phase	3
Number of terminals	14
Maximum output current	215 A
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	1600 V
surface mount	NO
Terminal form	UNSPECIFIED
Terminal location	UPPER
Base Number Matches	1

Preview

Download Datasheet

View All

Technische Information / Technical Information

Netz-Dioden-Modul

Rectifier Diode Module

DD B6U 215 N 12...18 (ISOPACK)

Elektrische Eigenschaften / Electrical properties

Höchstzulässige Werte / Maximum rated values

Periodische Spitzensperrspannung

repetitive peak reverse voltage

Stoßspitzensperrspannung

non-repetitive peak reverse voltage

Durchlaßstrom-Grenzeffektivwert (pro Element)

RMS forward current (per chip)

Ausgangsstrom

output current

= 110°C

= 45°C, KM 11

= 45°C, KM 33

= 35°C, KM 14 (V

= 45l/s)

= 35°C, KM 33 (V

= 90l/s)

= + 25°C...T

vj max

= - 40°C...T

vj max

RRM

1200, 1400

1600, 1800

RSM

1300, 1500

1700, 1900

FRMSM

125

215

127

215

A²s

Stoßstrom-Grenzwert

surge forward current

Grenzlastintegral

I²t-value

= 25°C, t

= 10ms

= T

vj max

, t

= 10ms

= 25°C, t

= 10ms

= T

vj max

, t

= 10ms

FSM

2200

1950

I²t

24200

19000

Charakteristische Werte / Characteristic values

Durchlaßspannung

forward voltage

Schleusenspannung

threshold voltage

Ersatzwiderstand

forward slope resistance

Sperrstrom

reverse current

Isolations-Prüfspannung

insulation test voltage

RMS, f = 50Hz, t = 1min

RMS, f = 50Hz, t = 1sec

= T

vj max,

R =

RRM

= T

vj max

= T

vj max

= T

vj max

, i

= 300A

max.

1,61

(TO)

0,75

1,6

mΩ

max.

ISOL

3,0

3,6

Thermische Eigenschaften / Thermal properties

Innerer Wärmewiderstand

thermal resistance, junction to case

pro Modul / per module,

= 120°rect

pro Element / per chip,

= 120°rect

pro Modul / per module, DC

pro Element / per chip, DC

thJC

max. 0,082

max. 0,490

max. 0,065

max. 0,390

°C/W

°C

Übergangs-Wärmewiderstand

thermal resistance, case to heatsink

Höchstzulässige Sperrschichttemperatur

max. junction temperature

Betriebstemperatur

operating temperature

Lagertemperatur

storage temperature

pro Modul / per module

pro Element / per chip

thCK

max. 0,033

max. 0,200

vj max

150

c op

- 40...+150

°C

stg

- 40...+150

°C

MOD-E1; R. Jörke

09. Feb 99

A /99

Seite/page 1(7)
