D1709N20T

Description
Rectifier Diode, 1 Phase, 1 Element, 1700A, 2000V V(RRM), Silicon,
CategoryDiscrete semiconductor    diode
File Size255KB,23 Pages
ManufacturerEUPEC [eupec GmbH]
Download Datasheet Parametric Compare View All

D1709N20T Overview

Rectifier Diode, 1 Phase, 1 Element, 1700A, 2000V V(RRM), Silicon,

D1709N20T Parametric

Parameter NameAttribute value
MakerEUPEC [eupec GmbH]
Reach Compliance Codeunknown
applicationGENERAL PURPOSE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)1.82 V
JESD-30 codeO-CEDB-N2
Maximum non-repetitive peak forward current18000 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature180 °C
Maximum output current1700 A
Package body materialCERAMIC, METAL-SEALED COFIRED
Package shapeROUND
Package formDISK BUTTON
Certification statusNot Qualified
Maximum repetitive peak reverse voltage2000 V
surface mountYES
Terminal formNO LEAD
Terminal locationEND
Base Number Matches1
Technische Information / Technical Information
Netz Gleichrichterdiode
Rectifier Diode
D 1709 N 20...24
T
vj
= - 40°C...T
vj max
V
RRM
N
Elektrische Eigenschaften / Electrical properties
Höchstzulässige Werte / Maximum rated values
Periodische Spitzensperrspannung
repetitive peak forward reverse voltage
Stoßspitzensperrspannung
non-repetitive peak reverse voltage
Durchlaßstrom-Grenzeffektivwert
RMS forward current
Dauergrenzstrom
mean forward current
Stoßstrom-Grenzwert
surge foward current
Grenzlastintegral
I²t-value
T
C
= 90 °C
T
vj
= 25°C, tp = 10 ms
T
vj
= T
vj max
, tp = 10 ms
T
vj
= 25°C, tp = 10ms
T
vj
= T
vj max
, tp = 10ms
2000
2200
2400
2300
2500
2700
1700
21.500
18.000
2.311
1.620
V
V
V
T
vj
= + 25°C...T
vj max
V
RSM
2100
V
V
V
A
A
A
A
A²s*10
3
A²s*10
3
I
FRMSM
I
FAVM
I
FSM
I²t
Charakteristische Werte / Characteristic values
Durchlaßspannung
forward voltage
Schleusenspannung
threshold voltage
Ersatzwiderstand
forward slope resistance
T
vj
= T
vj max
,
T
vj
= T
vj max
,
T
vj
= T
vj max
T
vj
= T
vj max
i
F
=
i
F
=
4 kA
700 A
v
F
v
F
V
(TO)
r
T
max.
max.
1,8
0,98
0,83
0,20
V
V
V
mΩ
T
vj
= T
vj max
Durchlaßkennlinie
on-state voltage
A=
B=
C=
D=
T
vj
= 25 °C
6,4014E-01
1,2359E-04
-1,0606E-02
1,2090E-02
i
R
7,2964E-01
8,9772E-06
5,9894E-03
8,4835E-03
max.
60
mA
v
T
=
A
+
B
i
T
+
C
Ln
(
i
T
+
1)
+
D
i
T
Sperrstrom
reverse current
T
vj
= T
vj max
, v
R
= V
RRM
Thermische Eigenschaften / Thermal properties
Innerer Wärmewiderstand
thermal resitance, junction to case
Kühlfläche / cooling surface
R
thJC
beidseitig / two-sided,Θ =180°sin
beidseitig / two-sided, DC
Anode / anode,
Θ
=180°sin
Anode / anode, DC
Kathode / cathode,
Θ
=180°sin
Kathode / cathode, DC
Übergangs- Wärmewiderstand
thermal resitance, case to heatsink
Höchstzulässige Sperrschichttemperatur
max. junction temperature
Betriebstemperatur
operating temperature
Lagertemperatur
storage temperature
Kühlfläche / cooling surface
beidseitig / two-sided
einseitig / single-sided
R
thJK
max.
max.
T
vj max
T
c op
T
stg
-40...+150
-40...+150
0,0035
0,0070
160
°C/W
°C/W
°C
°C
°C
max.
max.
max.
max.
max.
max.
0,0245
0,0223
0,0410
0,0388
0,0540
0,0514
°C/W
°C/W
°C/W
°C/W
°C/W
°C/W
prepared by: K.A.Rüther
approved by: J. Novotny
data of publication:
revision: 1
BIP AM
A20/00
Seite/page 1
