EP7 Interface Transformer for VDSL2 (annex B)
Preliminary Datasheet
25.10.2005
Ordering Code:
T2032/54/01
B78417A1922A003
Dimensions [mm]:
Schematics:
8
N3
6
7
N4
5
1
N1
3
2
N2
4
Marking:
EPCOS
middle block
date code
Electrical Characteristics:
(specified @25° if not mentioned otherwise) *) typical value
C
270 µH +/-10%
4:4:3:3
U=1500V
U=500V
< 1 µH (0.5 µH typ)
45 pF*
220 mOhm*
220 mOhm*
170 mOhm
180 mOhm
-83 dB*
f=10kHz, U=100mV, short: 2-3
f=50Hz, 1sec
f=50Hz, 1sec
f=100kHz,U=100mVshort(5-6-7-8),(3-2)
f=100kHz,U=100mV
Packaging:
Blistertape
Packaging unit: 320 Pcs
All values without tolerances are typical values !
Inductance: L(1-4)
N1:N2:N3:N4
HV: N1and N2 against N3 and N4
HV: N1and N3 against N2 and N4
L(leakage)( 1-4)
C(wind.)(1-2-3-4 / 5-6-7-8)
Rdc(Line)(1-3)
Rdc(Line)(2-4)
Rdc(Circuit)(8-6)
Rdc(Circuit)(7-5)
THD@138 kHz
Remarks:
Component is ROHS compliant
Urms=2.0V@100 Ohm (1-4)
Operating Temperature Range:
-40° to 85°
C
C
Page 1/3
