BZG05C...
Vishay Telefunken
Silicon Z–Diodes
Features
D
D
D
D
D
Glass passivated junction
High reliability
Voltage range 3.3V to 100V
Fits onto 5 mm SMD footpads
Wave and reflow solderable
15 811
Applications
Voltage stabilization
Order Instruction
Type
BZG05C3V3
Ordering Code
BZG05C3V3–TR
BZG05C3V3–TR3
Remarks
Tape and Reel (1.500 pcs)
Tape and Reel (6.000 pcs)
Absolute Maximum Ratings
T
j
= 25
_
C
Parameter
Power dissipation
Non repetitive peak
surge power dissipation
Junction temperature
Storage temperature range
Test Conditions
R
thJA
<30K/W, T
amb
=60
°
C
R
thJA
<100K/W, T
amb
=25
°
C
t
p
=100
m
s sq.pulse,
T
j
=25
°
C prior to surge
Type
Symbol
P
V
P
V
P
ZSM
T
j
T
stg
Value
3
1.25
60
150
–65...+150
Unit
W
W
W
°
C
°
C
Maximum Thermal Resistance
T
j
= 25
_
C
Parameter
Junction lead
Junction ambient
Test Conditions
mounted on epoxy–glass hard tissue, Fig. 1a
mounted on epoxy–glass hard tissue, Fig. 1b
mounted on Al–oxid–ceramic (Al
2
O
3
), Fig. 1b
Symbol
R
thJL
R
thJA
R
thJA
R
thJA
Value
30
150
125
100
Unit
K/W
K/W
K/W
K/W
Electrical Characteristics
T
j
= 25
_
C
Parameter
Forward voltage
Test Conditions
I
F
=0.2A
Type
Symbol
V
F
Min
Typ
Max
1.2
Unit
V
Document Number 85595
Rev. 7, 09-Mar-01
www.vishay.com
1 (4)
BZG05C...
Vishay Telefunken
Ozone Depleting Substances Policy Statement
It is the policy of
Vishay Semiconductor GmbH
to
1. Meet all present and future national and international statutory requirements.
2. Regularly and continuously improve the performance of our products, processes, distribution and operating
systems with respect to their impact on the health and safety of our employees and the public, as well as their
impact on the environment.
It is particular concern to control or eliminate releases of those substances into the atmosphere which are known as
ozone depleting substances ( ODSs ).
The Montreal Protocol ( 1987 ) and its London Amendments ( 1990 ) intend to severely restrict the use of ODSs and
forbid their use within the next ten years. Various national and international initiatives are pressing for an earlier ban
on these substances.
Vishay Semiconductor GmbH
has been able to use its policy of continuous improvements to eliminate the use of
ODSs listed in the following documents.
1. Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendments respectively
2 . Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the Environmental
Protection Agency ( EPA ) in the USA
3. Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C ( transitional substances ) respectively.
Vishay Semiconductor GmbH
can certify that our semiconductors are not manufactured with ozone depleting
substances and do not contain such substances.
We reserve the right to make changes to improve technical design and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each customer application
by the customer. Should the buyer use Vishay-Telefunken products for any unintended or unauthorized application, the
buyer shall indemnify Vishay-Telefunken against all claims, costs, damages, and expenses, arising out of, directly or
indirectly, any claim of personal damage, injury or death associated with such unintended or unauthorized use.
Vishay Semiconductor GmbH, P.O.B. 3535, D-74025 Heilbronn, Germany
Telephone: 49 ( 0 ) 7131 67 2831, Fax number: 49 ( 0 ) 7131 67 2423
www.vishay.com
4 (4)
Document Number 85595
Rev. 7, 09-Mar-01
