5962F9671901VRC Overview

ACT SERIES, 8-BIT TRANSCEIVER, TRUE OUTPUT, CDIP20

ACS245MS
January 1996
Radiation Hardened Octal
Non-Inverting Bidirectional Bus Transceiver
Pinouts
20 PIN CERAMIC DUAL-IN-LINE, MIL-STD-1835
DESIGNATOR CDIP2-T20, LEAD FINISH C
TOP VIEW
DIR
A0
A1
A2
A3
A4
A5
A6
1
2
3
4
5
6
7
8
9
20 VCC
19 OE
18 B0
17 B1
16 B2
15 B3
14 B4
13 B5
12 B6
11 B7
Features
• Devices QML Qualified in Accordance with MIL-PRF-38535
• Detailed Electrical and Screening Requirements are Contained in
SMD# 5962-96707 and Intersil’ QM Plan
• 1.25 Micron Radiation Hardened SOS CMOS
• Total Dose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >300K RAD (Si)
• Single Event Upset (SEU) Immunity: <1 x 10
(Typ)
-10
Errors/Bit/Day
• SEU LET Threshold . . . . . . . . . . . . . . . . . . . . . . . >100 MEV-cm
2
/mg
• Dose Rate Upset . . . . . . . . . . . . . . . . >10
11
RAD (Si)/s, 20ns Pulse
• Dose Rate Survivability . . . . . . . . . . . >10
• Latch-Up Free Under Any Conditions
• Military Temperature Range . . . . . . . . . . . . . . . . . . -55
o
C to +125
o
C
• Significant Power Reduction Compared to ALSTTL Logic
• DC Operating Voltage Range . . . . . . . . . . . . . . . . . . . . 4.5V to 5.5V
• Input Logic Levels
- VIL = 30% of VCC Max
- VIH = 70% of VCC Min
• Input Current
1µA at VOL, VOH
• Fast Propagation Delay . . . . . . . . . . . . . . . . 15ns (Max), 10ns (Typ)
12
RAD (Si)/s, 20ns Pulse
A7
GND 10
20 PIN CERAMIC FLATPACK, MIL-STD-1835
DESIGNATOR CDFP4-F20, LEAD FINISH C
TOP VIEW
DIR
A0
A1
A2
A3
A4
A5
A6
A7
GND
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
VCC
OE
B0
B1
B2
B3
B4
B5
B6
B7
Description
The Intersil ACS245MS is a Radiation Hardened octal non-inverting
bidirectional bus transceiver intended for two-way asynchronous
communication between data busses.
The ACS245MS utilizes advanced CMOS/SOS technology to achieve
high-speed operation. This device is a member of radiation hardened,
high-speed, CMOS/SOS Logic Family.
The ACS245MS is supplied in a 20 lead Ceramic Flatpack (K suffix) or a
Dual-In-Line Ceramic Package (D suffix).
Ordering Information
PART NUMBER
5962F9670701VRC
5962F9670701VXC
ACS245D/Sample
ACS245K/Sample
ACS245HMSR
TEMPERATURE RANGE
-55
o
C to +125
o
C
-55
o
C to +125
o
C
25
o
C
25
o
C
25
o
C
SCREENING LEVEL
MIL-PRF-38535 Class V
MIL-PRF-38535 Class V
Sample
Sample
Die
PACKAGE
20 Lead SBDIP
20 Lead Ceramic Flatpack
20 Lead SBDIP
20 Lead Ceramic Flatpack
Die
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
http://www.intersil.com or 407-727-9207
|
Copyright
©
Intersil Corporation 1999
Spec Number
File Number
1
518780
3198.1
