Lift |
Spacing 3.81 mm
AKZ1550/..-3.81-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.14 mm²
1.5 mm²
0.14 mm²
1.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
-
-
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
7.62
11.43
15.24
19.05
22.86
26.67
30.48
34.29
38.10
41.91
45.72
49.53
53.34
57.15
60.96
64.77
68.58
72.39
76.20
Article Designation
AKZ1550/2-3.81-GREEN
AKZ1550/3-3.81-GREEN
AKZ1550/4-3.81-GREEN
AKZ1550/5-3.81-GREEN
AKZ1550/6-3.81-GREEN
AKZ1550/7-3.81-GREEN
AKZ1550/8-3.81-GREEN
AKZ1550/9-3.81-GREEN
AKZ1550/10-3.81-GREEN
AKZ1550/11-3.81-GREEN
AKZ1550/12-3.81-GREEN
AKZ1550/13-3.81-GREEN
AKZ1550/14-3.81-GREEN
AKZ1550/15-3.81-GREEN
AKZ1550/16-3.81-GREEN
AKZ1550/17-3.81-GREEN
AKZ1550/18-3.81-GREEN
AKZ1550/19-3.81-GREEN
AKZ1550/20-3.81-GREEN
Article Number
51550020025F
51550030025F
51550040025F
51550050025F
51550060025E
51550070025E
51550080025D
51550090025D
51550100025D
51550110025D
51550120025D
51550130025D
51550140025D
51550150025D
51550160025D
51550170025D
51550180025D
51550190025D
51550200025D
PU
200
200
200
200
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.25 mm²
min
Stranded with Ferrule 1.0 mm²
max
Dimensions
Stripped Length
Materials
Clamp
Screw
Contact Spring
Brass
Bronze
Bronze
7.0 mm
Colours
GREEN
BLACK
BLUE
LIGHT GREEN
RAL6018
RAL9011
RAL5015
similar RAL 6018
RAL6018
RAL9011
Accessories
Figure
Designation
Bridge, 2-pole, BR/2-5.0/5.08-L7.5
Article Number
50000000015
RAL5015
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Counterparts (Spacing 3.81 mm)
Pin Strip/Terminal Blocks
STLZ1550
STLZ1590
STLZ1570
Bridge, 3-pole, BR/3-3.5/3.81-L7.5
50000000016
Bridge, 2-pole, insulated, BRI/2-7.0/7.62-
L7.5-LIGHT GREY
50000000018
Ratings
Usegroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
Pollution Degree
B
300 V
8A
C
-
-
D
300 V
8A
min
0.5 mm² (6 A)
0.5 mm² (6 A)
160 V
9A
III
max
1.5 mm² (9 A)
1.5 mm² (9 A)
0.25 Nm
M2
2.5 kV
3
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.6 kV
-
-
-
-
-
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.6 kV
